Efficient, reliable and consistently awesome
Built to last, this robust drive operates effectively and reliably even with the most demanding applications and in the most challenging environments.
VLT® AutomationDrive takes full advantage of all that the new digital age has to offer to ensure it completely fulfills the requirements of your applications and optimizes your processes throughout the entire lifecycle. The digital tools in MyDrive Suite complement the drive and equip you every step of the way from selection and system design through to commissioning and service.
Its cutting-edge thermal design and unique back-channel cooling make VLT® AutomationDrive one of the most compact and cost-efficient drives in the market. Intelligent maintenance and monitoring functions improve the productivity, performance, and uptime of your systems in the long term.
Current and power ratings
(High overload)
200-240 V AC
208 V……1.8-143 A , 0.25-37 kW
230 V……1.8-170 A , 0.34-50 Hp
380-500 V AC
400 V……1.3-990 A , 0.37-500 kW
460 V……1.2-890 A , 0.5-650 Hp
525-600 V AC
575 V……1.7-131 A , 1-100 Hp
525-690 V AC
575 V……1.6-889 A , 1.1-750 Hp
690 V……1.6-850 A , 1.1-710 kW
Ingress protection ratings
IEC: IP00, IP20, IP21, IP54, IP55, IP66
UL: Chassis, Type 1, Type 12, Type 4X
Features and benefits
-
Cybersecurity: security level 1 (SL1), for protection against unauthorized access
-
Condition-based monitoring (CBM) is integrated to achieve maximum uptime in your operations. CBM provides early warning of deterioration in sine-wave filters and early signs of cavitation. Activate CBM in the drive, using a token
-
Integrated Motion Controller (IMC) for automation made easy
-
Explore MyDrive® Suite for free software tools and downloads
-
VLT® Motion Control Tool MCT 10 offers a customized commissioning experience
-
DrivePro® Life Cycle Services proactively improve uptime of your plant
-
VLT® FlexConcept improves efficiency while reducing complexity in your system
-
Fits all motor technologies and fieldbus protocols: universally compatible
-
Commissioning and upgrades are easy due to plug-in technology
-
Back-channel cooling concept reduces energy costs, size of the cooling system, and extends drive lifetime
-
Automatic Motor Adaptation (AMA) for fast startup
-
Automatic Energy Optimization (AEO) for high system efficiency
-
Safe stop and Safe Torque Off ensure safe operation of the drive
-
‘Ruggedized’ design reduces the potential negative effects of vibration
Videos about VLT® AutomationDrive FC 302
Integrated Motion Controller
Perform high-precision positioning and synchronization operations with no need for extra modules or hardware. IMC gives you servo-like motion control in a standard drive.
Droop function
Easily switch between drives during load sharing. Use the droop function to protect motors from overloading and overheating, so machines can perform better for longer.
Videos about VLT® essentials
Learn to initialize a VLT® drive and discover more about features like Automatic Motor Adaption (AMA).
Documents
| Type | Name | Language | Valid for | Updated | Download | File type |
|---|---|---|---|---|---|---|
| Application guide | Encoder-less Safety using DOLD Module | English | Multiple | 15 Apr, 2017 | 5.9 MB | |
| Application guide | Siemens S7 PLC and FC 300 Profibus | English | Multiple | 20 May, 2005 | 852.8 KB | |
| Brochure | VLT AutomationDrive FC 301-302, VLT Decentral Drive FCD 302 SG | English | Multiple | 24 Mar, 2025 | 58.3 MB | |
| Brochure | VLT AutomationDrive FC 301-302, VLT Decentral Drive FCD 302 SG - US English Letter | English | United States | 19 Mar, 2025 | 70.4 MB | |
| Operating guide | VLT AutomationDrive FC302 90-710kW OperG | English | Multiple | 15 Feb, 2022 | 17.2 MB | |
| Application guide | VLT drives with integrated CBM | English | Multiple | 15 May, 2022 | 1.2 MB | |
| Application guide | VLT Integrated Motion Controller Application Guide | English | Multiple | 21 Feb, 2025 | 10.3 MB | |
| Design guide | VLT® Advanced Harmonic Filter AHF005-010 | English | Multiple | 28 Jan, 2026 | 7.3 MB | |
| Design guide | VLT® AutomationDrive FC 300 315–1200 kW | English | United States | 15 Nov, 2017 | 7.3 MB | |
| Programming guide | VLT® AutomationDrive FC 301 FC 302 SW 10.00 -49.1x | English | Multiple | 04 Feb, 2026 | 10.6 MB | |
| Design guide | VLT® AutomationDrive FC 302 315–1200 kW | English | Multiple | 15 Nov, 2017 | 7.3 MB | |
| Design guide | VLT® AutomationDrive FC 302 90-710kW | English | Multiple | 15 Sep, 2019 | 18.7 MB | |
| Design guide | VLT® AutomationDrive FC 302, 90-710 kW | English | Multiple | 15 Jan, 2018 | 13.6 MB | |
| Design guide | VLT® AutomationDrive FC301-302 0.25-75kW | English | Multiple | 15 Oct, 2019 | 35.9 MB | |
| Design guide | VLT® Brake Resistor MCE 101 | English | Multiple | 07 May, 2014 | 8.5 MB | |
| Programming guide | VLT® CANopen MCA 105 | English | Multiple | 15 Jun, 2015 | 1.5 MB | |
| Application guide | VLT® DeviceNet and Control logix 5550 | English | Multiple | 20 May, 2005 | 3.5 MB | |
| Programming guide | VLT® DeviceNet MCA 104 | English | Multiple | 14 Dec, 2015 | 931.0 KB | |
| Application guide | VLT® Drives Motor overload protection | English | Multiple | 19 Aug, 2008 | 212.6 KB | |
| Installation guide | VLT® FC 0.25-90 kW IG_language_Pack1 | German; English; Spanish, Castilian; French; Italian; Korean; Dutch, Flemish; Portuguese; Russian; Turkish; Ukrainian; Chinese | Multiple | 10 Apr, 2025 | 20.8 MB | |
| Programming guide | VLT® FC 301 302 Programming G. Addendum | English | Multiple | 15 Sep, 2020 | 23.2 MB | |
| Design guide | VLT® FC Series Output Filter Design G. | English | Multiple | 22 Feb, 2011 | 4.8 MB | |
| Programming guide | VLT® FC-Series Condition-based Monitoring PG | English | Multiple | 04 Nov, 2025 | 4.1 MB | |
| Design guide | VLT® Parallel Drive Modules, 250–1200 kW | English | Multiple | 15 Aug, 2017 | 16.4 MB | |
| Programming guide | VLT® PROFIBUS DP MCA 101 | English | Multiple | 13 Jan, 2016 | 2.0 MB | |
| Programming guide | VLT® PROFINET MCA 120 | English | Multiple | 24 Oct, 2014 | 1.6 MB |
