VLT® AutomationDrive FC 301 / FC 302

  • Overview
  • Documents
  • Drawings
  • Software
  • Related applications
  • Troubleshooting
  • Case stories

Efficient, reliable and consistently awesome

Built to last, this robust drive operates effectively and reliably even with the most demanding applications and in the most challenging environments.

VLT® AutomationDrive takes full advantage of all that the new digital age has to offer to ensure it completely fulfills the requirements of your applications and optimizes your processes throughout the entire lifecycle.

Its cutting-edge thermal design and unique back-channel cooling make VLT® AutomationDrive one of the most compact and cost-efficient drives in the market. Intelligent maintenance and monitoring functions improve the productivity, performance, and uptime of your systems in the long term.

Supply voltages and power range

  • 3 x 200-240 V...0.25-37 kW
  • 3 x 380-500 V...0.37 kW – 1.1 MW
  • 3 x 525-600 V...0.75-75 kW
  • 3 x 525-690 V...1.1 kW – 1.4 MW

Low harmonic drive

  • 3 x 380-480 V...132-450 kW

12-pulse drive

  • 3 x 380-500 V...250 kW – 1 MW
  • 3 x 525-690 V...250 kW – 1.4 MW

Features and benefits

Fits all motor technologies and fieldbus protocols: universally compatible

Commissioning and upgrades are easy due to plug-in technology

Back-channel cooling concept reduces energy costs, size of the cooling system, and extends drive lifetime

Automatic Motor Adaptation (AMA) for fast startup

Automatic Energy Optimization (AEO) for high system efficiency

Safe stop and Safe Torque Off ensure safe operation of the drive

Integrated Motion Controller (IMC) for automation made easy

Condition-based monitoring (CBM) is integrated to achieve maximum uptime in your operations

VLT® Motion Control Tool MCT 10 offers a customized commissioning experience

Explore MyDrive® Suite for free software tools and downloads

‘Ruggedized’ design reduces the potential negative effects of vibration

DrivePro® Life Cycle Services proactively improve uptime of your plant

VLT® FlexConcept improves efficiency while reducing complexity in your system
