Versatile performance

Unlock efficiency and effectiveness in your hydraulic integrated circuits (HICs) with our versatile logic elements. These elements can be seamlessly applied to design pressure, flow, and directional control circuits. Covering a wide range of pressure ratings and applications, our logic element valves serve as the foundation for engineering creative and tailored HIC solutions to perfectly meet your application needs.

Learn more

Features and benefits

Flow rating up to 400 l/min [106 US gal/min]

Pressure rating up to 350 bar [5000 psi]

Product range

Product Code Cavity Flow Pressure
CP300-4 SDC10-3 40 l/min [11 US gpm] 210 bar [3000 psi]
PCS13-10 SDC10-3 38 l/min [10 US gpm] 350 bar [5000 psi]
CP301-4 CP12-3 90 l/min [24 US gpm] 210 bar [3000 psi]
PCS13-12 C-12-3 58 l/min [15 US gpm] 350 bar [5000 psi]
CP302-4 SDC16-3 130 l/min [34 US gpm] 210 bar [3000 psi]
PCS13-16 SDC16-3 114 l/min [30 US gpm] 350 bar [5000 psi]
CP303-4 SDC20-3 284 l/min [75 US gpm] 210 bar [3000 psi]
Product Code Cavity Flow Pressure
CP310-4 SDC10-4 40 l/min [11 US gpm] 210 bar [3000 psi]
PCS14-10 SDC10-4 38 l/min [10 US gpm] 350 bar [5000 psi]
CP311-4 CP12-4 60 l/min [16 US gpm] 210 bar [3000 psi]
PCS14-12 C-12-4 58 l/min [15 US gpm] 350 bar [5000 psi]
CP312-4 SDC16-4 130 l/min [34 US gpm] 210 bar [3000 psi]
PCS14-16 SDC16-4 114 l/min [30 US gpm] 350 bar [5000 psi]
CP313-4 SDC20-4 340 l/min [90 US gpm] 210 bar [3000 psi]
CP310-6 SDC10-4 40 l/min [11 US gpm] 210 bar [3000 psi]
PFRS-12 C-12-5S 76 l/min [20 US gpm] 280 bar [4000 psi]
PFRS-16 C-16-5S 150 l/min [40 US gpm] 280 bar [4000 psi]
PFRS-20 C-20-5S 230 l/min [60 US gpm] 240 bar [3500 psi]
PFRD-12 C-12-5S 76 l/min [20 US gpm] 280 bar [4000 psi]
PFRD-16 C-16-5S 150 l/min [40 US gpm] 280 bar [4000 psi]
PFRD-20 C-20-5S 230 l/min [60 US gpm] 240 bar [3500 psi]
Product Code Cavity Flow Pressure
DPS2-10-B SDC10-3S 60 l/min [16 US gpm] 350 bar [5000 psi]
DPS2-12-B C-12-3S 114 l/min [30 US gpm] 350 bar [5000 psi]
DPS2-16-B SDC16-3S 189 l/min [50 US gpm] 350 bar [5000 psi]
DPS2-20-B C-20-3S 303 l/min [80 US gpm] 350 bar [5000 psi]
DPS2-10-S SDC10-3S 60 l/min [16 US gpm] 350 bar [5000 psi]
DPS2-12-S C-12-3S 114 l/min [30 US gpm] 350 bar [5000 psi]
DPS2-16-S SDC16-3S 189 l/min [50 US gpm] 350 bar [5000 psi]
DPS2-20-S C-20-3S 303 l/min [80 US gpm] 350 bar [5000 psi]
VLP 12/P2 NCS12/3 160 l/min [42 US gpm] 315 bar [4600 psi]
DPS2-10-T SDC10-3S 60 l/min [16 US gpm] 350 bar [5000 psi]
DPS2-12-T C-12-3S 114 l/min [30 US gpm] 350 bar [5000 psi]
DPS2-16-T SDC16-3S 189 l/min [50 US gpm] 350 bar [5000 psi]
DPS2-20-T C-20-3S 303 l/min [80 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
DPS2-8-P SDC08-3 30 l/min [8 US gpm] 350 bar [5000 psi]
CP700-1 SDC10-3 50 l/min [13 US gpm] 210 bar [3000 psi]
DPS2-10-P SDC10-3S 60 l/min [16 US gpm] 290 bar [4200 psi]
HLE10-CPC SDC10-3S 80 l/min [21 US gpm] 350 bar [5000 psi]
CP701-1 CP12-3S 150 l/min [40 US gpm] 350 bar [5000 psi]
DPS2-16-P SDC16-3S 189 l/min [50 US gpm] 290 bar [4200 psi]
DPS2-20-P C-20-3S 303 l/min [80 US gpm] 290 bar [4200 psi]
DPS2-8-V SDC08-3 30 l/min [8 US gpm] 350 bar [5000 psi]
CP700-2 SDC10-3 50 l/min [13 US gpm] 210 bar [3000 psi]
DPS2-10-V SDC10-3S 60 l/min [16 US gpm] 290 bar [4200 psi]
HLE10-CVO SDC10-3S 80 l/min [21 US gpm] 350 bar [5000 psi]
CP701-2 CP12-3S 150 l/min [40 US gpm] 350 bar [5000 psi]
DPS2-16-V SDC16-3S 189 l/min [50 US gpm] 290 bar [4200 psi]
DPS2-20-V C-20-3S 303 l/min [80 US gpm] 290 bar [4200 psi]
DPS2-8-R SDC08-3 30 l/min [8 US gpm] 350 bar [5000 psi]
CP700-3 SDC10-3 40 l/min [11 US gpm] 210 bar [3000 psi]
DPS2-10-R SDC10-3S 60 l/min [16 US gpm] 290 bar [4200 psi]
HLE10-OVC SDC10-3S 60 l/min [16 US gpm] 350 bar [5000 psi]
CP701-3 CP12-3S 80 l/min [21 US gpm] 350 bar [5000 psi]
DPS2-16-R SDC16-3S 189 l/min [50 US gpm] 290 bar [4200 psi]
DPS2-20-R C-20-3S 303 l/min [80 US gpm] 290 bar [4200 psi]
DPS2-8-F SDC08-3 30 l/min [8 US gpm] 350 bar [5000 psi]
CP700-4 SDC10-3 40 l/min [11 US gpm] 210 bar [3000 psi]
DPS2-10-F SDC10-3S 60 l/min [16 US gpm] 290 bar [4200 psi]
HLE10-OPO SDC10-3S 60 l/min [16 US gpm] 350 bar [5000 psi]
CP701-4 CP12-3S 76 l/min [20 US gpm] 350 bar [5000 psi]
DPS2-16-F SDC16-3S 189 l/min [50 US gpm] 290 bar [4200 psi]
DPS2-20-F C-20-3S 303 l/min [80 US gpm] 290 bar [4200 psi]
Product Code Cavity Flow Pressure
LE402 SDC20-2 350 l/min [93 US gpm] 350 bar [5000 psi]
LEV402 A21773 400 l/min [106 US gpm] 250 bar [3600 psi]
