VLT® AutomationDrive FC 360

  • Overview
  • Documents
  • Drawings
  • Software
  • Related applications
  • Troubleshooting
  • Case stories

Energy-efficient motor control

The VLT® AutomationDrive FC 360 is a compact, space-saving, general-purpose AC drive available in 5 frame sizes. Designed with ease-of-use, reliability and flexibility in mind, the basic, yet comprehensive features provide precise and energy-efficient motor control for a wide range of industrial applications.

The VLT® AutomationDrive is designed to perform reliably in harsh environments. The coated PCB reduces dust, moisture and particle issues and the maximum operating temperature is 55°C. Built-in features, such as PID controller, EMC filter, DC choke and brake chopper to 22 kW, save costs and installation space. IP 20 protection, a removable fan and an enhanced numerical display ensure fast setup and simpler maintenance.

Supply voltages and power range

  • 3 x 380 – 480 V    0.37 – 315 kW

Features and benefits

Reliable operation in many environments due ambient temperature of 50°C, unique cooling concept and coated PCB

5–15% energy savings and reduced operational costs due to Automatic Energy Optimizer function

Fast cleaning and extended lifetime thanks to removable cooling fan

No need for external controller due to built-in PID controller

Fast and easy commissioning as a result of enhanced numerical display and clear application selection guidance
