Precise control

Discover our complete line of relief valve solutions. From various sizes to diverse schematic types, we've got you covered. Our models are engineered to deliver a quick response, reduce noise, and enhance accuracy. Danfoss relief valves are reliable solutions to meet all your pressure control needs.

Learn more

Features and benefits

Flow rating up to 380 l/min [100 US gal/min]

Pressure rating up to 400 bar [5800 psi]

Product range

Product Code Cavity Flow Pressure
1DR2 SDC08-2 1.2 l/min [0.3 US gpm] 400 bar [5800 psi]
1DR30 SDC08-2 30 l/min [8 US gpm] 400 bar [5800 psi]
RV08-DR SDC08-2 30 l/min [8 US gpm] 250 bar [3600 psi]
RV1-10 SDC10-2 30 l/min [8 US gpm] 250 bar [3600 psi]
VEN 06 NCS06/2 40 l/min [11 US gpm] 315 bar [4600 psi]
VME 08 VME08 80 l/min [21 US gpm] 315 bar [4600 psi]
RV1-12 C-12-2 114 l/min [30 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
CP210-1 SDC10-2 45 l/min [12 US gpm] 210 bar [3000 psi]
CP211-1 CP12-2 76 l/min [20 US gpm] 210 bar [3000 psi]
1GR100 A881 150 l/min [40 US gpm] 210 bar [3000 psi]
Product Code Cavity Flow Pressure
CP208-1 SDC08-2 40 l/min [11 US gpm] 250 bar [3600 psi]
RV8-8 SDC08-2 30 l/min [8 US gpm] 350 bar [5000 psi]
CP200-1 SDC10-2 76 l/min [20 US gpm] 250 bar [3600 psi]
RV8-10 SDC10-2 76 l/min [20 US gpm] 350 bar [5000 psi]
CP201-1 CP12-2 150 l/min [40 US gpm] 250 bar [3600 psi]
RV3-12 C-12-2 132 l/min [35 US gpm] 350 bar [5000 psi]
RV3-16 SDC16-2 303 l/min [80 US gpm] 350 bar [5000 psi]
1LR300 A1126 380 l/min [100 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
RV5-10 SDC10-2 114 l/min [30 US gpm] 350 bar [5000 psi]
RV11-12 C-12-2 190 l/min [50 US gpm] 350 bar [5000 psi]
1AR100 A881 150 l/min [40 US gpm] 400 bar [5800 psi]
RV5-16 SDC16-2 300 l/min [80 US gpm] 350 bar [5000 psi]
1ARD100 A881 100 l/min [26 US gpm] 210 bar [3000 psi]
RV2-10 SDC10-2 114 l/min [30 US gpm] 350 bar [5000 psi]
RV10-POP SDC10-2 120 l/min [32 US gpm] 250 bar [3600 psi]
1ARC100 A881 150 l/min [40 US gpm] 400 bar [5800 psi]
1VR100 A3146 100 l/min [26 US gpm] 350 bar [5000 psi]
1VR200 A16102 200 l/min [52 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
CP200-7 SDC10-2 40 l/min [11 US gpm] 250 bar [3600 psi]
1CLLR100 A878 150 l/min [40 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
CP220-1 Catalog HIC 76 l/min [20 US gpm] 250 bar [3600 psi]
CP221-1 Catalog HIC 150 l/min [40 US gpm] 250 bar [3600 psi]

Documents

Documents
Type Name Language Valid for Updated Download File type
User guide ICS Relief Valves Technical Information English Multiple 22 Dec, 2022 1.5 MB .pdf
User guide ICS Relief Valves Technical Information English Multiple 20 Feb, 2024 3.2 MB .pdf
