Robust design for efficient and compact load holding

Explore our extensive check valve collection, featuring cartridge-style options (both standard and reverse direction) and in-line varieties. Our check valves and pilot-operated check valves aren't just compact and economical – they deliver optimal load holding performance. With numerous sizes and schematic options, we tailor our valves to meet your specific flow and pressure application needs. Rest easy with our robust, low-leakage designs, ensuring you can confidently apply them to your machine with unmatched reliability.

Features and benefits

Flow rating up to 310 l/min [82 US gal/min]

Pressure rating up to 420 bar [6000 psi]

Product range

Product Code Cavity Flow Pressure
CV3-4 C-4-2 7.6 l/min [2 US gpm] 350 bar [5000 psi]
CV08-NP SDC08-2 38 l/min [10 US gpm] 350 bar [5000 psi]
CV10-NP SDC10-2 80 l/min [21 US gpm] 350 bar [5000 psi]
CV11-12 C-12-2 114 l/min [30 US gpm] 350 bar [5000 psi]
CV11-16 SDC16-2 151 l/min [40 US gpm] 350 bar [5000 psi]
CV2-20 SDC20-2 227 l/min [60 US gpm] 210 bar [3000 psi]
3CA300 SDC20-2 300 l/min [80 US gpm] 350 bar [5000 psi]
CV6-4 C-4-2 7.5 l/min [2 US gpm] 350 bar [5000 psi]
CV6-10 SDC10-2 76 l/min [20 US gpm] 350 bar [5000 psi]
RV4-10 SDC10-2 45 l/min [12 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
RS 06 N/A 30 l/min [8 US gpm] 350 bar [5000 psi]
RS 10 N/A 60 l/min [16 US gpm] 350 bar [5000 psi]
RS 13 N/A 100 l/min [26 US gpm] 315 bar [4600 psi]
RS 19 N/A 140 l/min [37 US gpm] 280 bar [4000 psi]
RS 25 N/A 200 l/min [53 US gpm] 240 bar [3500 psi]
FPR11/4 N/A 220 l/min [58 US gpm] 240 bar [3600 psi]
FPR11/2 N/A 310 l/min [82 US gpm] 210 bar [3000 psi]
Product Code Cavity Flow Pressure
CP104-2 CP04-2 4.5 l/min [1.2 US gpm] 350 bar [5000 psi]
CP108-2 SDC08-2 20 l/min [5 US gpm] 350 bar [5000 psi]
CP100-2 SDC10-2 50 l/min [13 US gpm] 350 bar [5000 psi]
CP101-2 CP12-2 75 l/min [20 US gpm] 350 bar [5000 psi]
CP102-2 SDC16-2 150 l/min [40 US gpm] 350 bar [5000 psi]
CP103-2 SDC20-2 265 l/min [70 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
RPC 04 NCS04/3 20.5 l/min [5 US gpm] 350 bar [5000 psi]
SPC2-8 SDC08-3 19 l/min [5 US gpm] 240 bar [3500 psi]
RPC 06 NCS06/3 35 l/min [9 US gpm] 350 bar [5000 psi]
SPC2-10 SDC10-3 23 l/min [6 US gpm] 210 bar [3000 psi]
RPC 12 NCS12/3 90 l/min [24 US gpm] 315 bar [4600 psi]
4CK30 A6610 30 l/min [8 US gpm] 350 bar [5000 psi]
4SK30 A20090-T11A 30 l/min [8 US gpm] 350 bar [5000 psi]
POC1-10 SDC10-3S 60 l/min [15 US gpm] 350 bar [5000 psi]
4CK90 A12336 90 l/min [24 US gpm] 350 bar [5000 psi]
4SK90 A20092-T2A 90 l/min [24 US gpm] 350 bar [5000 psi]
4CKD90 A12336 90 l/min [24 US gpm] 420 bar [6000 psi]
4CK120 A877 120 l/min [32 US gpm] 350 bar [5000 psi]
4SK140 A20094-T17A 140 l/min [37 US gpm] 350 bar [5000 psi]
4CK300 A6935 300 l/min [80 US gpm] 350 bar [5000 psi]
RPV 06 NCS06/4 30 l/min [8 US gpm] 315 bar [4600 psi]
Product Code Cavity Flow Pressure
5CK30 A6610 30 l/min [8 US gpm] 350 bar [5000 psi]
5CK120 A877 120 l/min [32 US gpm] 350 bar [5000 psi]
5CK300 A6935 250 l/min [65 US gpm] 350 bar [5000 psi]
Product Code Cavity Flow Pressure
DPC2-8 SDC08-4 19 l/min [5 US gpm] 240 bar [3500 psi]
4CKKT50 A12744 25 l/min [7 US gpm] 300 bar [4300 psi]
CP410-1 Catalog HIC 80 l/min [21 US gpm] 210 bar [3000 psi]

Documents

Documents
Type Name Language Valid for Updated Download File type
User guide ICS Check Valves Technical Information English Multiple 22 Dec, 2022 2.5 MB .pdf
User guide ICS Check Valves Technical Information English Multiple 20 Feb, 2024 5.8 MB .pdf
