Reliable operation and excellent ride comfort
The VLT® Lift Drive is designed to provide reliable operation and excellent ride comfort for a minimum of 2.1 million cycles when running at an ambient temperature of below 45°C. Ideal for new projects or for retrofits, it operates without motor contractors and can be quickly and easily commissioned in less than 10 minutes.
Designed for all motors, including asynchronous, induction, permanent magnet, copper rotor and direct online PM motors, the VLT Lift Drive is suitable for both traction and hydraulic lifts in open- or closed-loop systems.
The compact design and intelligent cooling concept means it easily fits even into small installation spaces. And a range of built-in features eliminates the need for extra components. Scalable RFI filters minimize electromagnetic interference, integrated DC chokes suppress harmonics while ensuring the drives meet relevant EMC standards, and step-up, step-down transformers are not required.
Supply voltages and power range
- 380-400 V...4-55 kW
Features and benefits
Enhance travel comfort with our range of noise-reducing features
Use less energy with cooling fans that run only when required
Commission with no fuss since this drive fits all common feedback systems and there are just 10 parameters to set
Operate reliably in harsh conditions due to the specially coated circuit boards in this drive
Run reliably under intense vibration. Components remain firmly in place thanks to ‘ruggedization’
