VLT® AQUA Drive FC 202

  • Overview
  • Documents
  • Drawings
  • 3D models and drawings
  • Software
  • Learning
  • Case studies
  • Related applications
  • News

Built-in intelligence to keep your system running

Intelligence embedded in the VLT® AQUA Drive FC 202 automatically defines baseline parameters for water and wastewater applications, at all speeds and real-life operating cycles. In the event an issue is detected, Digital cascade control Hot Swap technology combined with back-up master functionality ensures reliable, stable and easy operation to help you stay up and running. In addition to the features provide by the VLT AQUA Drive, Danfoss offers DrivePro®-tection which provides up to a 6 year on-site warranty to insure continued operation of your drive.

Maximum energy efficiency for water, wastewater, and variable torque applications

The VLT® AQUA Drive FC 202 is designed to provide the highest level of performance of AC-motor-driven applications. Featuring a wide range of powerful standard features, which can be expanded with performance-improving options, the drive is equally suited to both new and retrofit projects.

The VLT® AQUA Drive can realistically offer first-year cost savings of between 10–30% compared to traditional drive solutions. Long equipment life, and low energy consumption and maintenance costs come together to provide the lowest cost of ownership. The quick and user-friendly setup reduces installation time ensuring a fast route to maximum energy efficiency and motor control.

Water and Wastewater Applications

The considerable daily load variation in water or wastewater treatment plants makes it economically feasible to introduce motor control on rotating equipment such as pumps and blowers.

Industrial VT Applications

The VLT® AQUA Drive the perfect match for Industrial VT applications including fans, pumps, blowers, and compressors. It is a direct replacement for the FC 322. Available in a wide range of industrial enclosures from protected chassis to IP 66 (NEMA 4 X Indoor).

Supply voltages and power range

  • 1 x 200-240 V...1.1-22 kW
  • 1 x 380-480 V...7.5-37 kW
  • 3 x 200-240 V...0.25-150 kW
  • 3 x 380-480 V...0.37 kW – 1 MW
  • 3 x 525-600 V...0.75-90 kW
  • 3 x 525-690 V...1.1 kW – 1.4 MW

Low harmonic drive

  • 3 x 380-480 V...132-450 kW

12-pulse drive

  • 3 x 380-500...250-1000 kW
  • 3 x 525-690...250-1400 kW

Simulate the savings— proof is in the details

Software download

Download the VLT® AQUA Drive Simulator and see how installing Danfoss drives will improve your efficiency.

Download the simulator

Features and benefits

Assets are protected thanks to specially designed software that prevents, for example, water hammering

Energy efficiency is maximized as a result of the drives control algorithms and design which focus on reducing heat loss

High energy savings related to air conditioning are ensured due to the unique back-channel-cooling concept that transfers 90% of heat away from the room

Electromagnetic interference and harmonic distortion are reduced thanks to the built-in, scalable RFI filter and integrated DC link chokes

Perfect system integration and adaptation to the application are possible due to freely programmable warnings and alerts

3–8% energy savings are achieved as a result of Automatic Energy Optimization

Get more information

View the AQUA brochure

VLT® AQUA Drive brochure

View the PDF of the North American VLT® AQUA Drive brochure for up to date information on the FC 202 and the water/wastewater industry.
