Reversing fan drives

Our fan drive HICs allow the machine designer to precisely control engine temperature, saving engine power and fuel. You can choose from six pre-engineered designs that provide speed control and reversing options for open circuit hydraulic fan drive systems.

Features and benefits

Proportional fan speed control:

  • Electronically match fan speed with cooling demand
  • Conserve engine power and fuel for the majority of operating conditions - as compared to non-proportional systems

Increased design flexibility:

  • The compact HIC valve can be placed in the most suitable location on the machine
  • Minimize fan system pressure losses when choosing the optimal fan drive HIC size for the application
  • Internal and external reversing pilot options available (40 LPM and 80 LPM )
  • Drain port included on all models for motor case drain
  • Robust IP69K Deutsch coil options available for all three sizes

Increased productivity:

  • Fan is reversible to purge (de-clog) coolers and radiators
  • Prevents overheating with purged cooler
  • More power available for useful work when radiator is not clogged

Reversing function allows you to:

  • Purge (declog) coolers and radiators
  • Prevent overheating

Automatic cleaning sequence programmed using PLUS+1®:

  • Manual or automatic activation

Product range

Model code Rated pressure Rated flow 3D model
RFDE-40-000 210 bar
(3000 psi)
10 - 40 lpm
(2.6 - 10.5 gpm)
STP file
RFDE-80-000 210 bar
(3000 psi)
20 - 80 lpm
(5.3 - 21.1 gpm)
STP file
RFD-120-000 210 bar
(3000 psi)
Up to 120 lpm
(31.7 US gpm)
STP file
Model code Rated pressure Rated flow 3D model
RFDE-40-PRV 210 bar
(3000 psi)
10 - 40 lpm
(2.6 - 10.5 gpm)
STP file
RFDE-80-PRV 210 bar
(3000 psi)
20 - 80 lpm
(5.3 - 21.1 gpm)
STP file
RFD-120-PRV 210 bar
(3000 psi)
Up to 120 lpm
(31.7 US gpm)
STP file

Documents

Documents
Type Name Language Valid for Updated Download File type
User guide ICS Fan Drive Hydraulic Integrated Circuit Technical Information English Multiple 18 Sep, 2020 1.8 MB .pdf
