PVED-CLS | Safe and intelligent steering
The Danfoss PVED-CLS actuator for electrohydraulic steering solutions is the first intelligent steering sub-system to integrate all safety functionality in the valve.
It is compliant with all current legislations and safety standards, including the Machinery Directive, and simplifies your system design, reduces development time, and accelerates your time to market with its cutting-edge connectivity, functionality, and integration.
Features and benefits
First intelligent sub-system to integrate all safety functionality in the valve
TÜV certified steering sub-system
CAN-BUS interface
Direct interface to electric mini wheel, joystick and auto guidance GPS (ISO 11873 curvature command)
PLUS+1® service tool
Provides optimum safety and reduces time to market with its simplified system architecture and maximum compatibility
