SystemStak Modular Valves

Increase efficiency

SystemStak is a revolutionary, compact system for sandwich-mounting modular valves between a directional control valve and a standard mounting surface. SystemStak gives you a full range of complementary pressure, flow and check valve functions, while saving space, reducing installation costs and increasing efficiency in hydraulic systems.

• Size – NG 4 to NG 25 (D02 to D08)
• Pressure – Up to 315 bar (4,500 psi)
• Flow – Up to 340 L/min (90 gal/min)

Simple installation, simple maintenance

Bolt-extender kits simplify valve installation by permitting each valve body to be separately and quickly installed and correctly torqued down. The kits also allow the directional valve to be removed for service or replacement without disturbing the stack. Working parts are serviceable without removing valves from the stack.

Why use SystemStak?

• Save space and improve design flexibility through a smaller, highly configurable package
• Reduce installation costs
• Improve operational efficiency
• Eliminate external leakage and boost resistance to contamination for improved overall reliability
• Simplify service and maintenance through easy access

Design flexibility

Each valve stack can be configured to provide the specific combination of functions required to meet the system’s needs. Available functions include:

• Relief
• Reducing
• Sequencing
• Check
• PO check
• Throttle
• Counterbalance

Don’t forget the subplates and bolts kits

To install industrial valves, you need subplates and bolt kits. This hardware is engineered especially for Vickers by Danfoss valves and manifolds to give your systems the flat surfaces and stiffness required for a reliable seal.
