Water-cooled brakes

Absorbs and dissipates huge thermal loads

Select from four different models of Airflex water-cooled brakes designed to meet the needs of even the most severe applications. Our advanced design features match your specific application requirements, including high horsepower absorption, continuous slip service, thermal load dissipation, dynamic tensioning, static holding and emergency stopping.

• Better energy dissipation - Improved fluid dynamics
• Continuous slip service - Absorbs and dissipates huge thermal loads
• Several torque capacities - 1:1 dynamic-to-static torque ratio

Continuous slip service

All models are designed to absorb and dissipate heavy thermal loads to provide continuous slip service all day long.

Patented piston design

Single or dual piston provides a wider range of applied tension with greater control. Standard single piston elements can be retrofitted with a dual piston powerhead to provide increased control.

Unique friction couple

A specially formulated friction material, interfacing with a copper alloy surface, eliminates the stick-slip characteristic associated with ordinary frictional devices. The dynamic coefficient of friction is greater than the static coefficient of friction.

Optional corrosion protection

For marine environment applications, we can add protective coatings to minimize corrosion.

WCB series

• 1000 HP per disc offers faster tripping time and allows brake downsizing
• Robust design eliminates copper cracking
• Self-supporting brake eliminates costly support brackets
• Higher coolant flow with 60% lower pressure drop
• Robust Teflon® tape seal eliminates leakage

WCB2 and WCBD series

• Special, high-coefficient linings deliver 50% more torque
• Dynamic coefficient of friction is greater than its static coefficient of friction
• Unique optional dual-piston design improves control
• Thermal capacities up to 5,200 HP (3,878 kW)
• Torque capacities available up to 7,254,450 lb•in (819,027 N•m)

WCS series

• Dynamic coefficient of friction is greater than its static coefficient of friction
• 1:1 dynamic-to-static torque ratio
• Thermal capacities up to 2,600 HP (1,939 kW)
• Torque capacities up to 1,545,000 lb•in (174,431 N•m)

WCSB series

• By incorporating both a water-cooled brake and an air-cooled brake, one package provides dynamic tensioning, static holding and emergency stopping capabilities, eliminating the need for multiple brake systems
• Specially formulated friction material interfaces with a copper alloy surface, to reduce or eliminate stick-slip characteristics
• Thermal capacities up to 3,900 HP (2,908 kW)
• Torque capacities up to 5,058,625 lb•in (571,119 N•m)
