Convenient and compact control for HVAC
Optimized for robust, basic operation of fans, pumps, and compressors, the VLT® HVAC Basic Drive has built-in functions that reduce initial costs and increase productivity. This user-friendly drive is the most compact unit in its class.
- Integrated DC coils reduce harmonics without the extra cost and space required for external devices
- VLT® Control Panel LCP 32 makes it easier to program the drive, with a choice of 8 languages in the display
VLT® HVAC Basic Drive FC 101 efficiently controls induction and permanent-magnet (PM) motors and can deliver up to 50% energy savings. In fact, the Automatic Energy Optimizer saves 3-5% energy from the second you turn it on. Achieve the lowest cost of ownership with a drive dedicated to ventilation, heating, and refrigeration applications.
Supply voltages and power range
- 3 x 200-240 V...0.25-45 kW
- 3 x 380-480 V...0.37-90 kW
- 3 x 525-600 V...2.2-90 kW
Features and benefits
-
HVAC features and harmonic mitigation are built into the drive, for low-complexity installation and to reduce investment cost
-
Saves up to 50% energy to reduce your operating costs
-
Unequalled robustness ensures you get maximum uptime
-
User-friendly to reduce time and cost in commissioning and operation
-
With the VLT® Mains-Free Interface accessory you can set drive parameters prior to installation, with no need for mains connection
-
Since FC 101 has UL LZGH2 certification in accordance with UL60335-2-40, UL60335-2-89, you can use A2L refrigerants in HVAC/R systems
Learn more about VLT® HVAC Basic Drive FC 101
VLT® Control Panel LCP 32 option
VLT® Control Panel LCP 32 offers you an easily readable graphical display with a range of time-saving functions. LCP 32 supports 8 languages.
Case story: Ventilation system upgrade
In modernizing the ventilation system of a hospital kitchen, FC 101 replaces a VLT® 5 drive after 40 years’ reliable service.
Videos about VLT® essentials
Learn to initialize a VLT® drive and discover more about features like Automatic Motor Adaptation.
