AKS 21 temperature sensor

AKS 21 temperature sensor

Pt 1000 general purpose temperature sensor capable of withstanding extreme high and low temperatures.  This sensor type can be surface mounted or inserted using available thermowells.

  • Refrigeration
  • Air conditioning
  • Heating

Sensor element is factory calibrated and complies with EN60751 Class B tolerances.

Features and benefits

Temperature range -70 to 180 °C

Resistance 1000 Ohm at 0°C

Silicone Cable

Enclosure IP67

18/8 stainless steel probe tip

Available thermowells for insertion applications

Documents

Documents
Type Name Language Valid for Updated Download File type
Data sheet Temperature Sensors, Type AKS 21 English Multiple 18 Jul, 2006 352.4 KB .pdf

Accessory

  • if (isSmallPicture) { MBT 120 } else if (isBigColumns) { MBT 120 } else { MBT 120 }
    MBT 120 thermowells

    MBT 120 thermowells can be used with AKS 21 to allow the sensors to be inserted into a liquid or gas flow. The welded stainless steel tube protects the probe tip and cable and resists pressures up to 50 bar. Available in various insertion lengths and process connections.

Related applications

The AKS 21 sensor is well-suited for the following applications:

Related solutions
