Efficient fire extinguishing with minimal water damage
Danfoss offers high-pressure pumps and valves for fire fighting, fire suppression and fire protection. The solutions are designed for more efficient fire extinguishing and minimizing water damage and risk of flooding.
By applying high-pressure fire fighting systems water is forced through micro nozzles at very high pressure to create a water mist that effectively combats fire.
The high-pressure extinguishing gives maximum protection by cooling through heat absorption and inerting the fire when the water expands through evaporation.
High-pressure water mist systems provide better fire suppression as well as better protection of personnel and surroundings by minimizing the potential water damage as the water mist evaporates.
The Danfoss PAH F high pressure pump is especially designed for fire fighting purposes with a flow capacity ranging from 14 to 115 l/min (3.7-30.3 gpm). The pumps are optimized for the use of tap water at temperatures from 2 to 50o C and pressures up to 160 barg (2,321 psig). The PAH F can be configured with all necessary high pressure components, valves, nozzles, etc. from the Danfoss product portfolio to form a complete solution with high reliability and long service life.
Features and benefits
Efficient fire extinguishing with minimized water damage
High performance and reliability
Solutions for fire fighting, fire suppression, fire protection
PAH F pumps
PAH F pumps have been designed to meet the demands within the fire fighting market. The PAH F pumps offer the same benefits as the PAH pumps – high reliability, long service life and compact size.
PAH high-pressure pumps are designed for tap water. PAH pumps are developed for various applications such as water hydraulic and dust suppression.
Pressure relief valves VPH/VRH
Reliable pressure relief valves for high-pressure applications. The relief valve is used for protecting the components of a system against overload as a result of a pressure peak.
VDHT 3/2 way zone drain valve
Flow range: 0-15 l/min, 0-3.96 gpm
Pressure range: 0-160 barg, 2,321 psig
VDHT/VDH 2/2 way valve
The VDH/VDHT directional valves are used to control the flow direction in high-pressure applications. The valves are available for a wide range of flows and pressures.
