Compact pressure transmitter program for severe hydraulic applications

The compact OEM pressure transmitter program is designed for use in severe hydraulic applications. The program consists of two series:

  • MBS 1200 – without integrated pulse-snubber
  • MBS 1250 – with integrated pulse-snubber

The integrated pulse-snubber offers a high degree of protection against cavitations and liquid hammer, and the well thought out design results in excellent vibration stability and an exceptional robustness. The high degree of EMI protection equips the pressure transmitter to meet most requirements.

Features and benefits

Designed for use in severe OEM applications

For medium and ambient temperatures up to 125 °C

All standard output signals: 4 – 20 mA, 0 – 5 V, 1 – 5 V, 1 – 6 V, 0 – 10 V, 10 – 90% ratiometric voltage

Wetted parts made of stainless steel

A wide range of pressure and electrical connections

EMC protection up to 100 V/m Dual output transmitter – for further information please contact Danfoss

Approvals and certificates

UL 508 recognized

ISO 7637 pulse 1-4

Product ordering key


Non-standard build-up combinations may be selected. However, minimum order quantities may apply.
Please contact your local Danfoss Office for further information.
