Compact pressure transmitter program designed for off high-way mobile hydraulic applications

The compact pressure transmitter program is designed for use in severe mobile hydraulic applications. The program consists of two series:

  • MBS 1200 – without integrated pulse-snubber
  • MBS 1250 – with integrated pulse-snubber

The integrated pulse-snubber offers a high degree of protection against cavitations and liquid hammer, and the well thought out design results in excellent vibration stability and an exceptional robustness. The high degree of EMI protection equips the pressure transmitter to meet most requirements.

Functional safety compliant through MTTFd and B10d reliability data for use where PLc performance level is required.

Features and benefits

High burst and over pressure capabilities due to fully welded design.

Safe ingress protection even in the harshest environment.

Excellent EMC immunity ensuring a failsafe measuring signal.

Zero drift due to excellent long term stability ensuring safety of the machine.

High tolerance to mechanical shock and vibrations

Design flexibility

Wetted parts of stainless steel

Wide range of electrical and pressure connections

For medium and ambient temperatures up to 125 °C

All standard output signals: Ratiometric voltage, 0 – 5 V, 1 – 5 V, 1 – 6 V, 0 – 10 V, 4 – 20 mA

Dual output transmitter and electronic pressure switch – for further information please contact Danfoss

Product ordering key


Non-standard build-up combinations may be selected. However, minimum order quantities may apply.
Please contact your local Danfoss Office for further information.
