High-pressure water mist systems

Customizable, all-in-one
high-pressure units for water mist

High-pressure water mist is critical to a wide range of processes, including humidification, dust suppression, fire suppression, adiabatic cooling, odor control, and disinfection.

For example, water mist is essential to the sawmill industry. In addition to saw blade lubrication and dust suppression, it helps ensure the controlled and uniform temperatures and humidity levels within wood kilns that are key to optimal drying, thereby mitigating the risks of quality defects like checking, warping and cracking.

Water mist systems are a versatile, cost-effective, and environmentally responsible choice that offer several advantages compared to alternative solutions. They are relatively simple to install and maintain in new or existing applications.

They use far less water – and create much less water damage – than sprinkler systems. They are non-toxic. And they provide attractive CAPEX and OPEX.

Danfoss makes water mist simple with an extensive and proven range of pre-configured high-pressure systems designed for easy installation, optimal energy efficiency, simple operation and maintenance, and convenient automation.

Danfoss high-pressure water mist systems are customizable to the customer’s specific needs. All systems come equipped with necessary safety features and can be configured according to customer requirements for water mist volume, control, and automation.

Features and benefits

Plug-and-play water mist systems that save energy & maintenance
- Designed for maximum performance in minimum space
- Built-in safety features to protect system in case of water outages or excess pressure
- You choose: flow range, valves, controls
- Ready to connect to water and electrical supplies
- Built, tested and certified prior to shipping
Powered by Danfoss PAH or PAHT high-pressure pumps
- Market-leading energy efficiency
- Zero risk of oil contamination
- Long service intervals – minimum 8,000 hours
- Work with municipal tap water (PAH) or ultra-pure water (PAHT)
Integrated Danfoss high-pressure valves and controls
- Corrosion and high-temperature resistant, dirt tolerant
- Low pressure drop
- Easy maintenance while still connected to the system
Decades of field-proven success in multiple industries and applications

The power pack portfolio

All-round water mist system, NPS

The all-round water mist system, NPS, for clean humidification and adiabatic cooling for many applications.

Applications areas:

High-pressure humidification and adiabatic cooling in HVAC systems for offices, server rooms, etc.
Open-space humidification systems in production halls, warehouses, etc.
Humidification and adiabatic cooling in verical farms, greenhouses and server rooms
Electrostatic discharge (ESD) control of data centers
Adiabatic outdoor cooling
Dust suppression and dust binding in manufacturing and clean rooms
Odor control and soil filter

NPS water mist system features:

Medium:	Ultra-pure/technical water
Max. outlet pressure:	100 barg (1,450 psig), continuous
Flow rates:	7.5 - 1000 l/h; 2 - 264 gal/h
HP pump:	PAHT 2 - 12.5
Motor/drive:	Available in 2 versions: 1) Constant speed, with standard IEC 3-phase 400 V, 50 Hz asynchronous motor for maximum flow or 2) Variable speed with built-in PID-controller and 24 V DC transmitter power supply for constant pressure at variable flow rates
Outlets:	1 - 2
Water filtration:	10”, 10 μm absolute, β ≥ 5,000

Want to know more about the NPS water mist system?

Download data sheet Contact local sales

Water mist systems for sawmills, lumber and general humidification, NWC

Water mist system for the sawmill and lumber industries and general humidification.

Application areas:

Saw blade cooling/lubrication
Humidity and temperature control of drying kilns
Dust suppression with atomized water
Humidification in ventilation systems
Stationary high-pressure cleaning
Humidification in general

NWC water mist system features:

Medium:	Tap water
Max. outlet pressure:	100 barg (1,450 psig), continuous
Flow rates:	7.5 - 1000 l/h; 2 - 264 gal/h
HP pump:	PAH 2 - 12.5
Motor/drive:	Available in 2 versions: 1) Constant speed, with standard IEC 3-phase 400 V, 50 Hz asynchronous motor for maximum flow or 2) Variable speed with built-in PID-controller and 24 V DC transmitter power supply for constant pressure at variable flow rates
Outlets:	1 - 12
Water filtration:	10” or 20", 10 μm absolute, β ≥ 5,000

Want to know more about the NWC water mist system?

Download data sheet More about wood applications Contact local sales

Highly configurable water mist system, NSU

Highly configurable water mist system for the sawmill and lumber industries and general humidification.

Application areas:

• Saw blade cooling/lubrication
• Humidity and temperature control of drying kilns
• Dust suppression with atomized water
• Humidification in ventilation systems
• Stationary high-pressure cleaning
• Humidification in general

NSU water mist system features:

Medium:	Tap water
Max. outlet pressure:	100 barg (1,450 psig), continuous
Flow rates:	7.5 - 6,800 l/h; 2 - 1,800 gal/h
HP pump:	PAH 2 - 100
Motor/drive:	Available in 2 versions: 1) Constant speed, with standard IEC 3-phase 400 V, 50 Hz asynchronous motor for maximum flow or 2) Variable speed with built-in PID-controller and 24 V DC transmitter power supply for constant pressure at variable flow rates
Outlets:	1 - 12
Water filtration:	10” or 20", 10 μm absolute, β ≥ 5,000

Want to know more about the NSU water mist system?

More about wood applications Contact local sales
