Low noise aluminum gear pumps

Low noise gear pump video

Evolutionary low noise patented gear pump technology

This low noise external gear pump guarantees outstanding performance throughout it's entire service life.

With a simple but sophisticated design, we offer a gear pump that not only is quieter. It also has a unique advantage over the most popular low noise gear pump. The patented design guarantees the pump will remain silent after many hours of heavy-duty operation. This offers costs savings over traditional gear pump by eliminating costs associated with external noise reduction devices.

The design offers up to 10 dB noise reduction over regular gear pumps. It is ideal for application where low noise and high efficiency are required. Typical applications include tractors, indoor lift trucks, aerial platforms, construction equipment, material handling, agricultural and lifting devices.

QUIETER PUMP – noise level emissions reduced by up to 10 dB(A)
LOW VIBRATION – flow pulsation reduced by a stunning 78%
DURATION – low noise performance guaranteed throughout the whole life of the pump
EFFICIENCY – higher efficiency compared to standard gear pumps
SAVINGS – cost, weight and footprint savings
LEGISLATION – helps meet legal NVH requirements
INTERCHANGEABLE – allows to fully replace our standard gear pumps

Technical specification

		Frame size	Frame size	Frame size	Frame size	Frame size	Frame size
SHHP2	cm³/rev [in³/rev]	8,0	011	014	017	019	022
Weight	kg [lb]	2.5 [5.5]	2.7 [5.8]	2.9 [6.3]	3.0 [6.5]	3.1 [6.7]	3.2 [7.0]
Moment of inertia of rotating components	x 10^-6 kg•m² [x 10^-6 lb•ft²]	32.4 [769]	38.4 [911]	47.3 [1122]	53.3 [1265]	59.2 [1405]	68.1 [1616]
Theoretical flow at max speed	l/min [US gal/min]	38.8 [9.2]	44.4 [11.7]	51.8 [13.7]	51.9 [13.7]	59.4 [15.7]	70.5 [18.6]
