The Danfoss EC-C24-D180 motor controller operates with low-voltage DC input and high-current output, offering excellent hardware and software performance. One motor control unit (MCU) provides real-time motor control while a second is used for diagnostics and safety, and the use of isolated CAN circuits reduces interference.

Features and benefits

Dual-MCU architecture
Support for IPM motors.
IP65 protection for reliability in severe environments
Motor speed is easy to control using CAN bus signals
Configurable CAN bus and Power Map curve
Ramp detection and speed limitation

Applications

Scissor lift
Mini e-SSL
Mini e-Excavator
Mini e-Wheel Loader
Mini AGV

Specifications

Nominal voltage 24V
Working voltage range 16.5V to 34V
Nominal current 80Arms, S2-60min
Max. current 180Arms, S2-1min
Max. power 2.2kW

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Data sheet	EC-C24-D180 low voltage inverter data sheet	English	Multiple	08 Sep, 2025	372.5 KB	.pdf
User guide	EC-C24-D180 low voltage inverter technical information	Chinese	Multiple	04 Jun, 2024	2.0 MB	.pdf
User guide	EC-C24-D180 Low voltage inverter user guide	English	Multiple	23 Apr, 2026	1.7 MB	.pdf
