VLT® Soft Starter MCD 600

  • Overview
  • Documents
  • 3D models and drawings
  • Software
  • Related applications
  • Case stories

Superior soft start performance for fixed-speed applications

The VLT® Soft Starter MCD 600 combines the latest in advanced controls and protections with an increased level of intelligence for superior performance in fixed-speed applications.

The MCD 600 is more flexible than ever to install, thanks to a wide variety of Ethernet and serial-based communication option cards, application-dedicated smart cards and support for eight languages.

An integrated bypass ensures both extremely high efficiency and harmonic-free operation at full speed, reducing energy consumed and required cooling capacity. Ease of use is in focus with features such as the pump-clean function, PowerThrough operation, and calendar or run time-based scheduling. More extensive motor and starter protections ensure more uptime.

Need more uptime and less maintenance?

Install a soft starter on your direct-on-line (DOL) or start-delta installation, to improve efficiency and protect the motor. Soft starters are free of harmonics and help to extend equipment lifetime. They are a useful complement to AC drives in optimizing motor drive applications.

Mains voltage range

  • 3 x 200-525 VAC (T5)
  • 3 x 380-690 VAC (T7)

Current range and enclosure

  • IP20: 20 – 129 A (Nominal)
  • IP00: 144 – 1250 A (Nominal)

Features and benefits

Inbuilt impeller cleaning assistance with Pump clean functionality

Easy application analysis with up to 348 events logged, as well as QR code scan for serial number and event data

Easy data access and reduced startup and upgrade time thanks to integrated USB port

More reliability, more uptime with expanded motor and controller protections

Flexibility for low speed applications, with Jog function

Improved uptime with PowerThrough function which uses 2-phase control if one phase is damaged by shorted SCR

Easy connectivity for the soft starter to Ethernet-based networks, such as PROFINET and EtherNet/IP

Programming is quick and easy thanks to three menu systems (Quick Menu, Application Setup and Main Menu), a four-line graphical display and a logic keypad

The best starting and stopping profile for the application is chosen using Adaptive Acceleration Control (AAC)

Installation costs are lower and there is less stress on the motor thanks to DC injection braking distributed evenly over three phases

Save space and reduce installation costs, thanks to the internal bypass contactors

Good asset protection thanks to Emergency mode, which keeps the fan or pump running for as long as possible in an emergency
