SVL-140B Parts program

SVL-140B Parts program DN 50 - 150 for industrial CO2 applications

SVL Flexline™ platform is now expanding to 140 bar MWP to meet an increasing demand of large manual valves in industrial design for large scale R744 transcritical CO₂ systems.

Starting up a new range of manual valves

First two functions in the new and separate range is the SVA Shut-Off valve and the FIA strainer housing, with the specific name SVA-140B and FIA-140B, referring to the 140 bar MWP. The valves are available in angle and straight connection in sizes from DN50 to DN150.

It is designed for favorable flow conditions and the FIA-140B can be fitted with the existing range of stainless-steel plain and pleated filter inserts from 150 to 500 microns.

Strainer inserts are shared with other FIA valves in the SVL platform.

The valves are especially applicable in medium and high-pressure part of the CO₂ transcritical system:

Upstream to HP valve
Upstream to By-pass valve
Upstream to MT compressors
Upstream to Hot gas defrost valves

Feature and Benefits

Range from DN 50 to 150 as Parts program

Straight and angle version valve body

Arrow for flow direction on valve body

Replaceable top part or filter insert

Refrigerant neutral gasket between valve body and top part

Pressure PS engraved in valve body

Buttweld and brazing connections

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Data sheet	Shut-off valve SVA-140B 140 bar (2030 psi) series	English	Multiple	01 Feb, 2024	3.4 MB	.pdf
Installation guide	Shut-off valves, type SVA-140B DN 50-150	Danish; English; Spanish, Castilian; Italian	Multiple	24 Nov, 2023	641.3 KB	.pdf
Data sheet	Strainer FIA-140B 140 bar (2030 psi) series	English	Multiple	01 Feb, 2024	3.3 MB	.pdf
Installation guide	Strainer, type FIA-140B DN 50-150	English	Multiple	06 Feb, 2024	607.1 KB	.pdf
Catalog	SVL Flexline™ 140 Bar Parts Program	English	Multiple	03 Jan, 2024	875.6 KB	.pdf

Videos

Efficient service of Danfoss SVA-140B shut-off valve

A guide on servicing the Danfoss SVA-140 B shut-off valve. Watch the video on steps to ensure a safe and reliable valve operation.

Software

Coolselector®2: We did complex — you do awesome

Coolselector®2 features unbiased calculations for the selection of refrigeration and air conditioning components based on the user’s requirements or based on standard operating conditions.

Coolselector®2
