DST P92S, pressure transmitter for SIL2 or PLd mobile hydralic applications

  • Overview
  • Documents
  • Approvals
  • Related applications
  • Learning
  • Articles

Enhancing safety, improving performance and reducing maintenance costs

DST P92S is a safety integrity level 2 (SIL 2) pressure sensor suitable for use in functional safety environment to serve the mobile hydraulic market. Ideal for industries such as material handling, construction, agriculture and forestry, the DST P92S pressure sensor is specifically designed to enhance safety, improve performance and reduce maintenance costs.

View the 3D model

The transmitter is suitable for use in a functional safety environment with a requirement of PLd, ISO 13849-1 or SIL2, IEC 61508. Further Danfoss holds a third party approval from TÜV ensuring an easy implementation into any safety system and improves your time to market.

Features and benefits

SIL 2 and PL d approved by TÜV

Complying with ISO13849-1 and IEC61508

Performs moisture and harness checks to detect moisture in the connector

Checks electrical interference on the signal line with 4-20mA/20-4mA dual output for the entire loop

Performs start-up and cyclic diagnosis every 30-40ms to detect possible failures, switching to safe state if a failure is detected.

Sealed transmitter and connector to prevent moisture ingress even in harshest environments

Compact in design to fit all applications (Hex22)

Temperature range: -40 to +85°C

Pressure range: 10-2,000 bar

Brochure - DST P92S pressure sensor - Danfoss

DST P92S Brochure

Learn more about the SIL2 pressure sensor for functional safety applications.

Modern Construction Depends on Large Machines that Operate Flawlessly Day After Day

Modern construction depends on large machines that operate flawlessly day after day. Avoiding downtime or faulty operation is critical.

Documents

Documents
Type Name Language Valid for Updated Download File type
Brochure Enhancing safety to improve performance (SIL2) English Multiple 27 Jun, 2016 336.3 KB .pdf
Data sheet Pressure transmitter SIL-2 DST P92S English Multiple 29 May, 2020 485.3 KB .pdf

Approvals

PLd DIN EN ISO 13849-1

SIL2 IEC 61508

CE

ECE

Approval Certificates

Type Name Approval authority Language Valid for Download Expiration date File type
EU-UK Declaration Danfoss EU-UK 078R0001.03 English Multiple 1.7 MB .pdf
Functional Safety Certificate SGS TÜV Saar FS/71/220/20/0501 German; English Multiple 79.0 KB .pdf
Functional Safety Certificate SGS TÜV Saar FS/71/220/20/0502 German; English Multiple 543.8 KB .pdf
Functional Safety Certificate SGS TÜV Saar FS/71/220/20/0503 German; English Multiple 78.8 KB .pdf
