Maximum flexibility
PVG 48 is designed for maximum flexibility based on proven PVG technology and modularity that simplifies the design process, manufacturing and aftermarket activities. PVG 48 enables flow up to 180 l/min work port flow and the complete actuator portfolio from PVG 32 can be applied, enabling a seamless integration with the pre-compensated valve familiy. It is directly stackable with PVG 16 and PVG 32 and can be stacked with PVG 128/256 via an interface plate.
Seamless Integration
Three valve sizes (PVG 16-32-48) can now be directly stacked into 1 valve group enabling customized solution for your exact and specified application control needs in a compact and cost-efficient package.
Load-sensing
By using PVG load-sensing technology in combination with a variable displacement pump, it’s possible to achieve a significant reduction in energy loss. PVG valves also reduce heat generation and increase efficiency and power density, which helps OEMs to meet the challenges posed by new diesel engine emissions legislation.
OEM and machine benefits
Modular design, providing a wide range of configuration possibilities
Load-independent flow control for precise operation and improved productivity
Load-sensing technology for higher efficiency, safety, reduced energy consumption, and longer system life
Product features
Configurable as advanced electrically controlled proportional valve as well as load sensing directional control valve
Prevention against work port pressure build up Individual work port pressure setting
Zero-leakage work modules
Introducing the PVG 48 proportional valve
Designed to easily integrate with the existing Danfoss Power Solutions’ high performance proportional valve platform.
Product range
-
if (isSmallPicture) {
For the most demanding applications, only the highest flow and the highest pressure will do. The PVG 128 and PVG 256 are made for controlling the toughest applications.
-
if (isSmallPicture) {
Low-flow PVG 16 covers simple to complex needs. Proven technology and components for customized valve stacks.
-
if (isSmallPicture) {
Get control of return flow with the Danfoss PVBM valve module – the only smartly integrated solution on the market.
-
if (isSmallPicture) {
PVSK modules are ideal for applications that have specific functionality or safety requirements.
-
if (isSmallPicture) {
PVG 32 is designed for maximum flexibility configurable as an advanced electrically controlled proportional valve. As well as a load sensing directional control valve.
Documents
| Type | Name | Language | Valid for | Updated | Download | File type |
|---|---|---|---|---|---|---|
| Service guide | PVG 16, 32, 48, 128, 256 Service and Parts Manual | English | Multiple | 13 Mar, 2024 | 29.0 MB | |
| User guide | PVG 48 proportional valve group technical information | English | Multiple | 21 Mar, 2024 | 6.5 MB | |
| User guide | PVG 48 Proportional Valve Group Technical Information | Japanese | Multiple | 25 Apr, 2024 | 5.5 MB |
