Your solid companion to deliver peak performance

DVG 60/100 open center directional control valves, complements our extensive spool valves portfolio, providing solutions and expertise for a wide range of machines and applications. With Danfoss DVG as your partner, operational efficiency is enhanced without compromising on features or cost, along with delivering in remarkably short lead times.

Key features and benefits

Exceptional return flow optimized for fast cylinder retraction

Market leading by-pass pressure drop and work port leakage​

Common interface enabling flexible configuration

Rapid delivery and an expansive distribution network

Outstanding electrohydraulic performance

Work port flows 60 and 100 lpm (15.8 & 26.4 gpm)
Work port pressure rating 310 bar (4500 psi)
Max. number of work sections 12 sections
Circuit types Series / Parallel / Tandem
Control types Electronic proportional & On/Off/ Mechanical/ Cable / Hydraulic/ Electro Pneumatic / Pneumatic
Ports Inlet/ Outlet 10 & 12 SAE / BSP
Work port 8 SAE (DVG 60 )
10 SAE (DVG 100)
Pressure drop DVG 60 Electric 2 bar / Mech 1 bar
DVG 100 Electric 3 bar / Mech 2 bar
High pressure relief valve High with pressure relief valves
Low without relief valve
Leakage Standard <10 cc/min - Special < 5 cc/min
