PVSK 256

  • Overview
  • Documents
  • Related products
  • Related applications

The oil supply cut-off module

PVSK modules are ideal for applications that have specific functionality or safety requirements.

The oil supply cut-off module, PVSK, is a vital part of our valve safety approach that includes the advanced, SIL 2 certified PVED-CX and PVSK with PVG 32.



With a complete line of PVSK modules, Danfoss offers an addition to the extensive PVG 32 product line. The PVSK module can be integrated in PVG 32 valve groups for open - as well as closed-center systems.

The PVSK can be controlled either mechanically or electronically with our electrohydraulic actuator, PVE.

PVSK – offering a wide range of options

The end mounted section either provides oil to the PVG valve bank, cuts off the oil supply, or diverts the oil to an alternative oil consumer

PVSK in-line solutions are available to either block-off downstream oil flow from the inlet, or divert oil out of an extra port

Functional Safety

Combining your PVG with PVSK and PVED-CX will provide you with a SIL 2 certified solution, which will meet the toughest requirements.

Documents

Documents
Type Name Language Valid for Updated Download File type
User guide PVSK Module with Integrated Diverter Valve and P-disconnect Function Technical Information Manual Chinese (CN) China 09 Mar, 2015 1.3 MB .pdf
User guide PVSK Module with Integrated Diverter Valve and P-disconnect Function Technical Information Manual English Multiple 09 Mar, 2015 3.1 MB .pdf
