R06 R family

The hoist receiver

R06 is one of the most cost effective solution for simple relay applications.

Features and benefits

Multi-band radio with full-duplex communication

Worldwide compatible multi-band radio. Possibility of full-duplex communication. Easily customizable via EEPROM.

Tether connection

Tether connection between the transmitter and receiver as an alternative to radio connection. In the event that radio control is not permitted or there are no charged batteries, the radio remote can be used with a wired connection between the transmitter and receiver. If a wired connection is used, the transmitter is powered by the receiver.

Removable EEPROM sim module

Removable memory card. Quick and easy restoration of service with a spare unit in the event of transmitter or receiver failure. If the transmitter is completely destroyed, the replacement can copy the EEPROM from the receiver.

External LEDs for troubleshooting

The external LEDs allow for fast and simple troubleshooting, to facilitate user detection of the incident as soon as possible.

Multiple transmitters systems

Possibility of working with multiple transmitters and a single receiver. The first device to link up assumes control of the machine.

Tandem systems

For situations requiring the use of two or more independent cranes moving simultaneously. The master transmitters can choose whether to work simultaneously with several receivers or independently with one of them.

Multiple receiver systems

Possibility of working with a single transmitter and multiple receivers at the same time.

Specifications

Receiver	R06
Stop function	Cat. 3 – PLd
Ingress protection	IP65/NEMA4
Frequency band	Multiband (400 – 930 MHz)
AC Power Supply	48 - 230 Vac ±25% (Multivoltage) / 18-30 Vac
DC Power Supply	8-36 Vdc
Antenna	Internal
Removable EEPROM	Internal
Signaling	Internal
ON / OFF outputs (Max.)	6
Analogue Outputs (Max.)	N/A
CANopen	Yes
ON / OFF inputs (Max.)	4
Analogue Inputs (Max.)	1
Maximum output Current	6A
Working Temperature Range	-20C + 70C (-4F + 158F)
Weight	640 grams
Dimensions (LxWxH mm)	151 x 129 x 61
Cable connection	Yes
Range limiter	Yes
Associated Transmitters	T70 1/ IK2
