Ikore transmitters

Ikore transmitter

State of the art lifting technology

Ikore represents the new generation of handheld units and is ready to operate in the 2.4 GHz universal band.

With the user perspective in mind, Ikore has been designed with a small size and weight without sacrificing the robustness. The improved ergonomics prevents the user from suffering postural fatigue. This handheld transmitter is our newest solution for standard overhead crane applications.

Ikore

The new handheld for standard EOT cranes

Specifications

Transmitter	Ikore
Stop function	Cat. 3 - PLe. EN12849-1 and SIL 3 IEC 61508 / IEC 62061
Ingress protection	IP65/NEMA4
Anti condensation system	N/A
Frequency band	2405MHz to 2475MHz 20dBm/100mW
Main mechanisms (max. #)	Pushbutton (7) + START + STOP
Removable EEPROM	External
Battery model	4 AAA (Ikore) / BT11K (IkoreB)
Battery life	>80 hours / 8 hours (100% duty cycle)
Operating temperature range	-20C +70C (-4F +158F)
Weight (with battery)	315 grams
Dimensions LxWxH mm	174.5x68x56
Harness	Hand strap/shoulder strap
Display	N/A
Cable connection	N/A
Range limiter	N/A
Associated receivers	R11

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Installation guide	ikore and R11 Installation Guide	English	Multiple	12 Feb, 2025	488.0 KB	.pdf
Installation guide	IKORE B and R11 Installation Guide	English	Multiple	28 Sep, 2021	470.1 KB	.pdf
Data sheet	IKORE B Transmitter Data Sheet	Chinese	China	23 Nov, 2020	1.9 MB	.pdf
Data sheet	IKORE B transmitter remote control data sheet	English	Multiple	09 Jul, 2024	1.7 MB	.pdf
User guide	IKORE B Transmitter User Manual	Portuguese	Multiple	24 Jan, 2025	3.1 MB	.pdf
User guide	IKORE B Transmitter User Manual	English	Multiple	15 Jan, 2026	4.5 MB	.pdf
User guide	IKORE B Transmitter User Manual	Spanish, Castilian	Multiple	29 May, 2019	3.0 MB	.pdf
Data sheet	IKORE Transmitter Data Sheet	Spanish, Castilian	Multiple	01 May, 2019	471.0 KB	.pdf
Data sheet	IKORE Transmitter Data Sheet	English	Multiple	16 Feb, 2022	471.8 KB	.pdf
Data sheet	IKORE Transmitter Data Sheet	Chinese	Multiple	03 Nov, 2020	580.7 KB	.pdf
User guide	IKORE Transmitter User Manual	English	Multiple	13 Jan, 2026	3.1 MB	.pdf
User guide	IKORE Transmitter User Manual	Portuguese	Multiple	12 Dec, 2024	3.0 MB	.pdf
User guide	IKORE Transmitter User Manual	Spanish, Castilian	Multiple	29 May, 2019	3.0 MB	.pdf
