Ikompact transmitters

Ikompact 8 transmitter

Mini handheld transmitter for mobile applications

Ikompact is our handheld unit exclusively designed for mobile applications. This transmitter works in the 2.4 GHz universal band and it is used in utility/service cranes.

Ikompact comprises two models, Ikompact 8 (8 push buttons) and Ikompact 12 (12 push buttons), which depend on the number of functions different projects will need.

Specifications

Transmitter	Ikompact
Stop function	Cat. 3 - PLe. EN12849-1 and SIL 3 IEC 61508 / IEC 62061
Ingress protection	IP65/NEMA4
Anti condensation system	N/A
Frequency band	2.4 GHz
Main mechanisms (max. #)	8 or 12 push buttons
Auxiliary mechanisms	Stop button
Removable EEPROM	External
Battery model	4 AAA Alkaline batteries
Operating temperature range	-20C +70C (-4F +158F)
Weight (with battery)	250 grams
Harness	Lanyard/Hook
Display	N/A
Cable connection	N/A
Range limiter	N/A
Associated receivers	MP08 TR2400

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Data sheet	Ikompact Data Sheet	Spanish, Castilian	Multiple	01 May, 2019	620.5 KB	.pdf
Data sheet	IKOMPACT transmitter data sheet	English	Multiple	25 Apr, 2024	620.9 KB	.pdf
Data sheet	IKOMPACT Transmitter Data Sheet	Chinese	Multiple	01 Mar, 2021	734.6 KB	.pdf
User guide	Ikompact Transmitter User Manual	English	Multiple	28 Mar, 2019	3.0 MB	.pdf
User guide	Ikompact Transmitter User Manual	Spanish, Castilian	Multiple	30 May, 2019	3.0 MB	.pdf
