The best fit for direct machine mounting
Designed for simplicity and robustness, the VLT® Decentral Drive FCD 302 is a user-friendly product with high performance and a strong protection degree.
A decentral-drive solution eliminates the need for space-consuming control cabinets. And, with the drives placed near the motor, there is no need for long-screened motor cables.
With the VLT Decentral Drive FCD 302, all the options are built into the unit reducing the number of boxes to be mounted, and the connections and terminations in the installation. As a result, labor costs and the risks of failure are dramatically reduced.
Supply voltages and power range
- 3 x 380-480 V...0.37-3 kW
Features and benefits
Installation is flexible as the drive adapts to any brand of motor
Servicing is fast and easy due to the pluggable twin-part design
Cleaning is easy thanks to the drive’s smooth surface
Cable savings are possible as a result of the integrated power and fieldbus looping terminals
Direct connection to a PC is possible thanks to the integrated USB port
The need for PLC capacity is reduced due to the built-in smart logic controller
