Danfoss Turbocor® TTH/TGH

Experience the benefits of oil-free technology in high lift applications

The world’s first oil free compressor optimized for high lift applications

The Danfoss Turbocor^® TTH/TGH oil-free centrifugal compressor is specifically designed for high lift applications such as air-cooled chillers in hot ambient climates, heat recovery, heat pumps or thermal storage. The TTH/ TGH compressor provides a high-performance alternative to the traditional oiled screw compressor that is more efficient, quieter and with a smaller physical footprint.

In addition, oil free technology has no performance degradation over the life of the compressor unlike traditional oiled screw compressors which can incur performance degradation due to excess oil and mechanical wear over time.

As part of the Danfoss long-term refrigerant strategy, the TTH/TGH compressor is available with low GWP refrigerant options. The TTH model utilizes R134a and is compatible with non-flammable R513A while the TGH model uses ultra-low GWP HFO-1234ze.

Features and benefits

Zero performance degradation and no mechanical wear over the life of the compressor
Outstanding energy efficiency at part load
Compact, lightweight and simple system design reduce installation and maintenance costs
Soft Start reduces in-rush current at startup
Exceptionally quiet operation - 70 dB(A), up to 8 dB(A) quieter vs comparable size screw compressor
ETL Listed and CE Compliant

Two compressor models are available

TTH375	TGH285
High Lift up to 6.2 PR and water-cooled capability	High lift up to 6.2 PR and water-cooled capability
Low, medium and standard temp applications	Low, medium and standard temp applications
380, 400 and 460V	380, 400 and 460V
R134a and low GWP R513A	Ultra low GWP HFO1234ze

Turbocor® fact sheet

Danfoss Turbocor^® portfolio of oil free centrifugal compressors, models TT, TG and VTT, deliver innovative technology that reduces operating costs and maintenance for your air conditioning applications.

Open fact sheet

Danfoss Turbocor® TTH/TGH Compressor

The Danfoss Turbocor^® TTH/TGH oil-free, magnetic bearing compressor, optimized for high lift applications.

Download the brochure

brochure clip for Turbocor TTH and TGH compressors

Videos

Oil-free technology highlighted within a ghost shell of the Danfoss Turbocor compressor types TTH and TGH

Danfoss Turbocor® for High lift applications

The new Danfoss Turbocor^® TTH/TGH oil free compressors, offer an expanded operating map to support higher lift applications. These applications include air-cooled chiller operation at high ambient temperatures, heat pumps, low temperature process, and thermal storage applications.
