Reliable pressure measurement, even under harsh environmental conditions
The compact pressure transmitter, type MBS 3000, is designed for use in almost all industrial applications, and offers a reliable pressure measurement, even under harsh environmental conditions.
The compact heavy duty pressure transmitter MBS 3050 with integrated pulse-snubber is designed for use in hydraulic applications with severe medium influences like cavitation, liquid hammer or pressure peaks and offers a reliable pressure measurement, even under harsh environmental conditions.
The flexible pressure transmitter program covers different output signals, absolute and gauge (relative) versions, measuring ranges from 0 – 1 to 0 – 600 bar and a wide range of pressure and electrical connections.
Excellent vibration stability, robust construction, and a high degree of EMC/EMI protection equip the pressure transmitter to meet the most stringent industrial requirements.
Features and benefits
-
Designed for use in severe industrial and hydraulic environments
-
Resistant to cavitation, liquid hammer and pressure peaks (MBS 3050)
-
Enclosure and wetted parts of acid-resistant
-
Stainless steel (AISI 316L)
-
Pressure ranges in relative (gauge) or absolute from 0 up to 600 bar
-
All standard output signals: 4 – 20 mA, 0 – 5 V, 1 – 5 V, 1 – 6 V, 0 – 10 V, 1 – 10 V
-
A wide range of pressure and electrical connections
-
Temperature compensated and laser calibrated
Approvals and certificates
- Complies with ATEX Ex II Ex 3G Ex-nA IIAT3
