For pavement snow melt applications...
The DS-2C and DS-5C electric snow melt controllers are designed for pavement snow melting applications.
They can be used as a stand alone controller or as a sensor for larger control systems.
Power Control Voltage:
DS-2C: 100-277V universal input
DS-5C: 100-277V field selectable
Max. Heating Load:
Max. Ambient Temperature:
-40°F to +185°F (-40°C to +85°C)
Enclosure Type: NEMA 3R
Mounting: Wall/pole mounted, outdoors
Dimensions (HxWxD): 4.75" x 7.00" x 2.75" (121mm x 178mm x 70mm)
|Type||Name||Language||Valid for||Updated||Download||File type|
|Data sheet||DS-2C Controller Datasheet||English||United States||01 Aug, 2016||241.4 KB|
|Operating guide||DS-2C Rain/Snow Sensor Controller Installation Manual VIHWB122||English||United States||05 Jun, 2015||323.3 KB|
|Operating guide||DS-5C Installation Manual||English||United States||26 Jul, 2016||426.6 KB|
|Data sheet||DS-5C Snow Melt Controller Datasheet||English||United States||25 Jul, 2016||369.2 KB|
|Catalog||Electric Heating Product Catalog VKAPA1022_2||English||United States||14 Mar, 2019||2.6 MB|
|Data sheet||GX Snow Melting Mat Specification sheet||English||United States||19 Dec, 2008||36.6 KB|
|Brochure||GX Snow Melting System Trifold Brochure||English||United States||21 Aug, 2017||1.4 MB|
GX cables - for snow melting
GX Snow melting cables are available in a wide range of voltages (208V, 240V, 277V, 480V, 600V) and lengths (from 40ft. to 940ft). The GX cable allows for more flexibility during installation as the cables may be spaced at different increments depending on your application area.
GX850 Snow Melt Controllers
The AWARD WINNING Danfoss GX Dual Zone Automatic Control Panel (ACP) and GX850M are the most optimal solution for keeping any area free of ice and snow. The GX 850 acts on information received from sensors which register both temperature and moisture, then calculates the information ensuring that the heat will only be turned on when snow and/or ice is present. The result is optimal performance with maximum energy savings and minimum operating costs.
