A safe and convenient solution

Part of Danfoss' ICV Flexline™ series, ICLX valves are two-step servo-operated main valves with pilot solenoid valves. ICLX valves can be used in suction lines for opening against high differential pressure, such as after hot gas defrosting in large industrial refrigeration systems using  HCFC, HFC, R717 (ammonia) or R744 (CO2).

ICLX valves offer safe, flexible, and convenient installation, operation, and service. For example, the standard ICV Flexline™ housing makes the ICLX valve, a true plug-and-play solution with easy and time-saving switching between functions.

The ICLX valve is factory-configured to open in two steps, though it can easily be configured to open in only one step. In the two-step configuration, step one opens to approximately 10% of the capacity after the pilot solenoid valves are energized. Step two opens automatically when the pressure differential across the valve has decreased to approximately 18 psig (1.25 bar).

The ICLX valve is comprised of five main components: valve body, top cover, function module, and two pilot solenoid valves. On ICLX 32–150 models, the top cover and function module are factory-assembled.

Features and benefits

Hermetically sealed Teflon valve plates and gas-tight piston rings eliminate leaks

Normally closed solenoid valves minimize system risks

Direct weld eliminates pipe flanges, increasing system safety and simplifying installation

Outstanding flow characteristics are ideal for systems where low pressure drop is required

Available with butt weld, socket weld, and solder connections

Designed for industrial refrigeration applications with a maximum working pressure of 754 psig (52 bar)

A red-scaled product representing the brochure for Danfoss ICLX 2-step solenoid valves for industrial refrigeration

Reduce lifecycle costs, increase savings and design freedom

The ICV Flexline™ control valves are not only designed to give you savings and design freedom, but they also provide a reliable, safe and green solution for your needs - both now and in the future.


Type Name Language Valid for Updated Download File type
Installation guide 2-step solenoid valve, ICLX 100-150 English; Spanish, Castilian; French; Polish; Portuguese; Russian; Chinese (CN) Multiple 06 Feb, 2018 2.9 MB .pdf
Data sheet 2-step solenoid valve, ICLX 32-150 English United States 05 Apr, 2018 4.7 MB .pdf
Data sheet 2-step solenoid valve, type ICLX 32-150 English Multiple 25 Feb, 2021 7.0 MB .pdf
Installation guide 2-step solenoid valve, Type ICLX 32-65 English; Spanish, Castilian; French; Polish; Portuguese; Russian; Chinese (CN) Multiple 06 Feb, 2018 3.0 MB .pdf
Application guide Application Handbook - Automatic Controls for Industrial Refrigeration Systems Arabic; Bulgarian; Czech; Danish; German; Greek (modern); English; Spanish, Castilian; Estonian; Persian; Finnish; French; Irish; Hebrew (modern); Hindi; Croatian; Hungarian; Indonesian; Icelandic; Italian; Japanese; Kazakh; Korean; Lithuanian; Latvian; Macedonian; Norwegian Bokmål; Dutch, Flemish; Polish; Portuguese; Romanian, Moldavian, Moldovan; Russian; Slovak; Slovenian; Serbian (RS); Swedish; Tamil; Thai; Turkish; Ukrainian; Vietnamese; Chinese (CN) Multiple 06 Oct, 2020 17.3 MB .pdf
Brochure Danfoss ICLX two-step servo-operated main valves---A superior solution of safety and convenience (sales brochure) English Multiple 01 Dec, 2014 433.5 KB .pdf
Brochure Reduce lifecycle costs Increase savings and design freedom - The ICV Control Valve - member of the Flexline family English Multiple 17 Apr, 2015 4.2 MB .pdf
Data sheet Spare parts and accessories - Spare part kits - ICV valves - ICS, ICM, ICLX English Multiple 20 Sep, 2017 19.1 MB .pdf


Coolselector®2 app icon

The truth is Cool(selector®2)

Coolselector®2 features unbiased calculations for the selection of refrigeration and air conditioning components based on the user’s requirements or based on standard operating conditions.
