High-pressure pumps for reverse osmosis applications

Energy efficient pumps for desalination

With Danfoss high-pressure APP pumps tailored to Sea Water Reverse osmosis (SWRO) applications you will get one of the most reliable and sustainable pumps for desalination. The APP pumps can be used in almost any SWRO application – land-based, offshore or marine. Mounted in containers or trains, the APP pumps can contain several pumps in parallel to secure uninterrupted and sufficient supply at any time.

Danfoss has pioneered axial piston pump technology in challenging hydraulic applications for several years. With more than 15 patents, a strong precision engineering heritage and world-class production know-how in Duplex, Super Duplex and carbon-reinforced PEEK, Danfoss designs and produces the most advanced high-pressure pumps available for reverse osmosis. The APP pump is oil-free, using only water for lubrication. Most pumps can be delivered with ATEX and API 674 approvals.

The Danfoss APP pumps are available in various sizes from 0.6 m3/h to 92 m3/h for use in small and medium-sized SWRO facilities.

Features and benefits

Extensive application know-how
Highest efficiency rates in the industry
Compact and small – half size of competing pumps
Long time between service intervals
Easy and service-friendly design
Simple and reliable with high uptime
Short pay-back time

Make fresh water in a sustainable and energy-efficient way

Reduce energy costs by applying the Danfoss APP pump

Download brochure

Resort, onshore reverse osmosis - Danfoss

Compact and simple design
Due to its high energy-efficiency and reliability, SWRO has turned into one of the most sustainable and cost effective desalination solutions for land-based, offshore and marine applications. The technology is reliable and safe with high-pressure pumps forcing seawater through desalination membranes to create fresh water. Danfoss supplies expertise and unique technologies that can offer your business high efficiency, low maintenance and flexible configuration.

Energy

With efficiency rates up to 92%, the APP pump technology offers the highest efficiency in the industry.

Maintenance

The simple construction of the pump offers reliable operation with long service intervals and easy maintenance.

Footprint

The small and compact size of the pump allow flexible configuration in almost any environment.

Product range

APP 16-22 high pressure pump

Pressure range: Max outlet pressure: 80 barg/1,160 psig
Min. outlet pressure, inlet: 2-5 barg/29-72.5 psig
Flow range: 13,3-21,9 m3/h - 58.6-96.4 gpm
Speed: 700 to 1,500 rpm

APP 0.6-1.5 high pressure pump

Pressure range: Max outlet pressure: 80 barg/1,160 psig
Min. outlet pressure, inlet: 0.5-5 barg/7.3-72.5 psig
Flow range: 0.2-1.3 m3/h - 0.9-5.7 gpm
Speed: 700 to 3,450 rpm

APP 5.1-10.2 high pressure pump

Pressure range: Max outlet pressure: 80 barg/1,160 psig
Min. outlet pressure, inlet: 0.5-5 barg/7.3-72.5 psig
Flow range: 1.9-10.7 m3/h - 8.4-47.1 gpm
Speed: 700 to 1,800 rpm

APP 21-43 high pressure pump

Pressure range: Max outlet pressure: 80 barg/1,160 psig
Min. outlet pressure, inlet: 2-5 barg/29-72.5 psig
Flow range: 12.3-44.9 m3/h - 54.2-197.6 gpm
Speed: 700 to 1,700 rpm

APP 1.5-3.5 high pressure pump

Pressure range: Max outlet pressure: 80 barg/1,160 psig
Min. outlet pressure, inlet: 0.5-5 barg/7.3-72.5 psig
Flow range: 0.4-3.5 m3/h - 1.8-15.4 gpm
Speed: 700 to 3,450 rpm
