Versatile, reliable and consistently awesome

Built to last, this robust drive operates effectively and reliably even with the most demanding applications and in the most challenging environments.

VLT® AutomationDrive takes full advantage of all that the new digital age has to offer to ensure it completely fulfills the requirements of your applications and optimizes your processes throughout the entire lifecycle.

Its cutting-edge thermal design and unique back-channel cooling make VLT® AutomationDrive one of the most compact and cost-efficient drives in the market. And new intelligent maintenance features and a range of DrivePro® services proactively improve productivity, performance and uptime.

Supply voltages and power range

  • 3 x 200-240 V...0.25-37 kW
  • 3 x 380-500 V...0.37 kW – 1.1 MW
  • 3 x 525-600 V...0.75-75 kW
  • 3 x 525-690 V...1.1 kW – 1.4 MW

Supply voltages and power range

  • 3 x 200-240 V...0.25-37 kW
  • 3 x 380-500 V...0.37 kW – 1.1 MW
  • 3 x 525-600 V...0.75-75 kW
  • 3 x 525-690 V...1.1 kW – 1.4 MW

Features and benefits

A wide operating temperature range of -25°C to +50°C without derating ensures reliable operation when your applications take your drive to the extremes

The flexible, modular design concept provides an extraordinarily versatile motor control solution

The new VLT® Wireless Communication Panel LCP 103 communicates wirelessly with MyDrive® Connect making it easier to perform commissioning, operation, monitoring and maintenance tasks

Back-channel cooling concept reduces costs, energy consumption and the size of the cooling system

New ‘ruggedized’ design reduces the potential negative effects of vibration

The need for PLC capacity is reduced thanks to Smart Logic Control

Low lifetime costs are ensured as the drive is highly resistant to wear and tear

The lifetime of electronics is prolonged due to back-channel cooling for enclosures D, E and F

Commissioning and upgrades are easy due to plug-in technology

High-precision position and synchronization thanks to availability of Integrated Motion Controller throughout the entire product range

Features such as intelligent heat management, Safe stop and Safe Torque Off ensure safe and energy-efficient operation of the drive

VLT® Motion Control Tool MCT 10 offers a customized commissioning experience

Integrated Motion Controller

High-precision positioning and synchronization with reduced costs and system complexity

To optimize performance, many applications across all industry sectors have a need for precise positioning and synchronization. These applications include:

  • rotary tables
  • packaging machines
  • labelling machines
  • conveyors
  • extruders
  • palletizers

To date, positioning and synchronization operations have been performed using servo drives. However, servo equipment is expensive; it is difficult to commission and requires additional cabling. And, as servo drives do not work with open loop control systems, there is a high failure rate. Many applications do not require the high dynamic performance offered by a servo drive. An alternative was to use an AC drive. But, until now, an additional internal or external module or an encoder on the motor was required.

Danfoss Drives has developed an innovative alternative to servo control. The Integrated Motion Controller (IMC) is functionality that enables an AC drive to perform high-precision positioning and synchronization operations without the need for additional modules or hardware. IMC is now configurable in the software of the VLT® AutomationDrive FC 302.

IMC has many advantages. It works with all conventional motor technologies, with closed loop or open loop control, and offers sensorless homing with torque detection. Drives are adapted to the applications through simple parameterization. This means that knowledge of servo technology or programming languages is not required. As no encoder or additional cables are needed, engineering, installation and commissioning time and costs can be reduced.

Read iPaper and download

Documents

Documents
Type Name Language Valid for Updated Download File type
Programming guide - AU VLT® Automation Drive FC 300 SW 7.62/8.1 English United States 01 Jan, 2018 5.2 MB PDF
Design guide - AJ VLT® AutomationDrive FC 300 315–1200 kW English United States 01 Nov, 2017 7.3 MB PDF
Programming guide - AU VLT® AutomationDrive FC 300 SW8.43/48.40 English Multiple 01 Oct, 2019 6.0 MB PDF
Brochure - AD VLT® AutomationDrive FC 301/302 English Multiple 12 Jul, 2019 5.2 MB PDF
Design guide - AJ VLT® AutomationDrive FC 302 315–1200 kW English Multiple 01 Nov, 2017 7.3 MB PDF
Design guide - AJ VLT® AutomationDrive FC 302, 90-710 kW English Multiple 01 Jan, 2018 13.6 MB PDF
Design guide - AJ VLT® AutomationDrive FC 302, 90-710 kW English United States 01 Jan, 2018 14.6 MB PDF
Design guide - AJ VLT® AutomationDrive FC301/302 0.25-75kW English Multiple 01 Oct, 2019 35.9 MB PDF
Design guide - AJ VLT® AutomationDriveFC 301/302 0.25-75kW English United States 18 Dec, 2013 7.3 MB PDF
