Efficient, reliable and consistently awesome
Built to last, this robust drive operates effectively and reliably even with the most demanding applications and in the most challenging environments.
VLT® AutomationDrive takes full advantage of all that the new digital age has to offer to ensure it completely fulfills the requirements of your applications and optimizes your processes throughout the entire lifecycle.
Its cutting-edge thermal design and unique back-channel cooling make VLT® AutomationDrive one of the most compact and cost-efficient drives in the market. Intelligent maintenance and monitoring functions improve the productivity, performance, and uptime of your systems in the long term.
Supply voltages and power range
- 3 x 200-240 V...0.25-37 kW
- 3 x 380-500 V...0.37 kW – 1.1 MW
- 3 x 525-600 V...0.75-75 kW
- 3 x 525-690 V...1.1 kW – 1.4 MW
Low harmonic drive
- 3 x 380-480 V...132-450 kW
12-pulse drive
- 3 x 380-500 V...250 kW – 1 MW
- 3 x 525-690 V...250 kW – 1.4 MW
Features and benefits
Fits all motor technologies and fieldbus protocols: universally compatible
Commissioning and upgrades are easy due to plug-in technology
Back-channel cooling concept reduces energy costs, size of the cooling system, and extends drive lifetime
Automatic Motor Adaptation (AMA) for fast startup
Automatic Energy Optimization (AEO) for high system efficiency
Safe stop and Safe Torque Off ensure safe operation of the drive
Integrated Motion Controller (IMC) for automation made easy
Condition-based monitoring (CBM) is integrated to achieve maximum uptime in your operations
VLT® Motion Control Tool MCT 10 offers a customized commissioning experience
Explore MyDrive® Suite for free software tools and downloads
‘Ruggedized’ design reduces the potential negative effects of vibration
DrivePro® Life Cycle Services proactively improve uptime of your plant
VLT® FlexConcept improves efficiency while reducing complexity in your system
Videos about VLT® AutomationDrive FC 302
Integrated Motion Controller
Perform high-precision positioning and synchronization operations with no need for extra modules or hardware. IMC gives you servo-like motion control in a standard drive.
Droop function
Easily switch between drives during load sharing. Use the droop function to protect motors from overloading and overheating, so machines can perform better for longer.
Videos about VLT® essentials
Learn to initialize a VLT® drive, and discover more about features like VLT® Wireless Communication Panel LCP 103 and Automatic Motor Adaption.
Documents
| Type | Name | Language | Valid for | Updated | Download | File type |
|---|---|---|---|---|---|---|
| Programming guide | VLT® Automation Drive FC 300 SW 7.62/8.1 | English | United States | 01 Jan, 2018 | 5.2 MB | |
| Design guide | VLT® AutomationDrive FC 300 315–1200 kW | English | United States | 01 Nov, 2017 | 7.3 MB | |
| Programming guide | VLT® AutomationDrive FC 300 SW9.12/48.9X | English | Multiple | 30 Dec, 2022 | 7.0 MB | |
| Brochure | VLT® AutomationDrive FC 301/302 SG | English | Multiple | 01 Oct, 2021 | 6.7 MB | |
| Design guide | VLT® AutomationDrive FC 302 315–1200 kW | English | Multiple | 01 Nov, 2017 | 7.3 MB | |
| Design guide | VLT® AutomationDrive FC 302, 90-710 kW | English | Multiple | 01 Jan, 2018 | 13.6 MB | |
| Design guide | VLT® AutomationDrive FC301/302 0.25-75kW | English | Multiple | 01 Oct, 2019 | 35.9 MB |
