Energy storage and power conversion enabler

The VACON® NXP Grid Converter plays a key role in supporting clean power conversion in distributed networks with or without energy storage.

By enabling connection of energy storage to AC grids, supporting hydrogen electrolysis, and facilitating AC grids onboard vessels or island applications in remote areas, it fulfils a unique function. Without the grid converter none of these would be possible.

The grid converter facilitates load sharing and is highly versatile, for easy integration into diverse networks. Its importance cannot be overstated; use of a grid converter is a must in reaching emission targets.

Green hydrogen

In Power-to-X projects such as hydrogen electrolysis, VACON NXP Grid Converter gives you the high-efficiency power conversion with low harmonics that you need. Scalable power conversion supports you to grow your green hydrogen capabilities over time, balance the grid, and maintain low operational costs for economical hydrogen production. With an EU target of 40 GW electrolyzer capacity by 2030, this power converter is the bridge between renewable energy and hard-to-decarbonize sectors.

Smart Danfoss grid converter

VACON NXP Grid Converter for smart grids improves stability in the grid by supporting a diverse range of energy generators and energy storage systems. By enabling peak shaving, it in turn reduces the capital investment required for grid infrastructure. It is certified for grid code compliance in a wide range of countries, for fast system certification for system integrators.

Shore supply power conversion

When used with a shore-supply solution, VACON NXP Grid Converter allows electrical power to be sourced from the local grid, rather than the ship’s main engine or generators. This process, sometimes known as ‘cold ironing’, has a significantly positive impact on fuel economy. It causes reductions in CO2, NOx and SOx emissions, as well as noise and vibration levels.

Shaft generator

VACON NXP Grid Converter can also be applied to shaft-generator solutions, ensuring that propulsion machinery is able to operate at various speeds. The shaft generator decouples the shaft from the mains, which allows better electrical quality and improved fuel economy. Additionally, power can either be taken from or entered into the propeller shaft. This is particularly useful for ships that often alternate their speeds as it creates fuel savings and minimizes exhaust emissions by up to 15%. It also creates an emergency mode meaning that the vessel can operate even if the main engine fails.

Support for system integrators

Danfoss supports system integrators (SI) in designing their systems to bid on projects. Our aim is to help customers by providing tools and reference designs to make their system design easier. For instance, Danfoss can provide configurable 3D models as well as 2D general arrangement drawings from our product offering.

Endorsed by the World Alliance for Efficient Solutions as a Solar Impulse Efficient Solution.

Endorsed by the World Alliance for Efficient Solutions as a Solar Impulse Efficient Solution.

The 1000 Efficient Solutions comprise the very best the world has to offer in clean and profitable solutions to protect the environment. VACON® NXP Grid Converter was assessed on the criteria of viability, deployability, and sustainability.

Read about Solar Impulse Efficient Solutions
Read about the VACON® NXP Grid Converter endorsement

Supply voltages and power range

Air cooled:

  • 3 x 380-500 V...180-1100 kW
  • 3 x 525-690 V...200-1200 kW

Liquid cooled:

  • 3 x 400-500 V...160-1800 kW
  • 3 x 525-690 V...210-1800 kW

Features and benefits

Reduced fuel consumption as electrical power can be sourced from the grid

Lower CO2, NOx and SOx emissions as the main engine can be shut down

Conforms to ABS and DNV standards

Improved energy efficiency as engine speed can be optimized

Liquid and air cooled solutions available

Facilitates fast system certification for distributed smart grids, thanks to compliance with global grid codes

Protects critical industrial processes with Intelligent DC backup

Simplified logistics and good protection with containerized solutions

Faster, more cost effective engineering thanks to reference designs

Facilitates active and reactive load sharing via droop function

Shore supply with Dutch grid converter

Reducing port emissions

Discover how shore supply systems equipped with VACON® NXP Grid Converter help port authorities meet emission targets
