MBS 3000 series, general purpose pressure transmitters

  • Overview
  • Documents
  • Approvals
  • Related applications
  • Related solutions
  • Learning

Reliable pressure measurement, even under harsh environmental conditions

The pressure transmitter, type MBS 3000, is designed for use in almost all industrial applications, and offers a reliable pressure measurement, even under harsh environmental conditions.

MBS 3000 is designed to cover requirements in most environments and therefore it is a highly flexible product widely used in most applications.

View the 3D model

The version consists of two series:

  • MBS 3000 – without integrated pulse-snubber
  • MBS 3050 – with integrated pulse-snubber

The integrated pulse-snubber offers a high degree of protection against cavitation and liquid hammer, and the well thought out design results in excellent vibration stability and an exceptional robustness.

The flexible pressure transmitter program covers different output signals, absolute and gauge (relative) versions, measuring ranges from 0 – 1 to 0 – 600 bar and a wide range of pressure and electrical connections.

Excellent vibration stability, robust construction, and a high degree of EMC/EMI protection equip the pressure transmitter to meet the most stringent industrial requirements.

Features and benefits

Designed for use in almost all industrial environments

Resistant to cavitation, liquid hammer and pressure peaks (MBS 3050)

Enclosure and wetted parts of acid-resistant in it's fully welded design - Stainless steel (AISI 316L)

High Performance

Robust, shock- and vibration-resistant solution with high-electromagnetic compatibility harsh water, and air, and marine applications.

Longer component lifespan and reduced warranty cost.

Pressure ranges in relative (gauge) or absolute from 1 up to 600 bar

All standard output signals: 4 – 20 mA, 0 – 5 V, 1 – 5 V, 1 – 6 V, 0 – 10 V, 1 – 10 V

A wide range of pressure and electrical connections

Danfoss pressure transmitter | Walkthrough

How to install a Danfoss pressure transmitter | Walkthrough

Documents

Documents
Type Name Language Valid for Updated Download File type
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 Czech Czech Republic 01 Dec, 2020 576.0 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 German Multiple 01 Dec, 2020 602.8 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 Spanish, Castilian Multiple 01 Dec, 2020 582.4 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 French Multiple 01 Dec, 2020 523.3 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 Italian Italy 01 Dec, 2020 580.5 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 Dutch, Flemish Netherlands 01 Dec, 2020 585.9 KB .pdf
Data sheet Pressure transmitter digitally compensated for general industrial purposes, MBS 3000 and MBS 3050 Polish Poland 01 Dec, 2020 544.5 KB .pdf

Approvals

Complies with ATEX Ex II Ex 3G Ex-nA IIAT3

CE marked

CSA

UL

TSSA

GOST

Approval Certificates

Type Name Approval authority Language Valid for Download Expiration date File type
EU Declaration Danfoss EU 064G9615.09 English Multiple 1.3 MB .pdf
Metrological Certificate GOST OC.C.30.004.A 53828-1 Russian Multiple 1.5 MB .pdf
Pressure Safety Certificate TSSA CRN.0F18477.5123467890YTN English Multiple 10.9 MB .pdf
Explosive Safety Certificate UL E227388 English Multiple 68.7 KB .pdf
Electrical Safety Certificate UL E31024 English Multiple 350.0 KB .pdf
Electrical Safety Certificate UL E311982 English Multiple 804.3 KB .pdf
Electrical Safety Certificate UL E494625 English Multiple 104.7 KB .pdf
