MBS 1600 pressure transmitters – specifically designed for the wind turbine industry

The compact MBS 1600 pressure transmitters are built tough to withstand the harsh environments that wind power applications face. The dedicated range of pressure transmitters comes with all the needed electrical and pressure connections for easy integration into the nacelle.

The programme consists of two series:

  • MBS 1600 – without integrated pulse-snubber
  • MBS 1650 – with integrated pulse-snubber

View the 3D models:

The integrated pulse-snubber offers a high degree of protection against cavitations and liquid hammer, and the well thought out design results in excellent vibration stability and an exceptional robustness.

The high degree of EMI protection equips the pressure transmitter to meet most requirements.

Features and benefits

Immunity to electrical noise in the harshest environments (direct-coupled, transient, and case noise)

Mis-wire protected

Short-circuit protected

MTTFd > 100 years

For medium and ambient temperatures up to 125 °C

Output signals: 4 – 20 mA

Wetted parts made of stainless steel

Complying with the standards and product specifications requested by larger OEMs in the wind turbine industry

Wind turbine brochure

Learn more about our product offerings for the wind industry.

Documents

Documents
Type Name Language Valid for Updated Download File type
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 Chinese (CN) Multiple 22 Jul, 2020 589.4 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 Danish Multiple 22 Jul, 2020 519.3 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 German Multiple 22 Jul, 2020 554.6 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 Italian Multiple 22 Jul, 2020 527.8 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 French Multiple 22 Jul, 2020 520.6 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 English Multiple 22 Jul, 2020 517.5 KB .pdf
Data sheet OEM transmitters for heavy-duty applications, MBS 1600 and MBS 1650 Spanish, Castilian Multiple 22 Jul, 2020 521.7 KB .pdf

Approvals

CE

UL

EN13849-1 PLc compliant

Approval Certificates

Type Name Approval authority Language Valid for Download Expiration date File type
EU-UK Declaration Danfoss EU-UK 063R1011.05 English Multiple 1.5 MB .pdf
