Perfect control for your application
The ICM motor operated valves from Danfoss ICV Flexline™ series are quick and simple to handle, install and service due to their low weight and compact design. The valve is designed to regulate the expansion process in liquid lines and to control pressure or temperature in dry and wet suction lines and hot gas lines.
The ICM valves are ready for the refrigerants of the future, designed and tested to withstand a maximum working pressure of up to 52 bar (754psi) in a media temperature range of –60 to +120°C [–76 to +248°F]. This makes them suitable for the natural refrigerant CO₂, ammonia and other future high pressure refrigerants.
The ICM motor valve is available as a complete valve and as parts programme.
Features and benefits
Fast and easy handling, installation and service
Low weight and compact design
Suitable for natural, high-pressure refrigerants, e.g. CO₂
Second-to-none control characteristics
Provides high suction pressure and better COP for energy savings
Reduce lifecycle costs, increase savings and design freedom
The ICM Flexline™ motor valves are not only designed to give you savings and design freedom, but they also provide a reliable, safe and green solution for your needs - both now and in the future.
