Maksimal energieffektivitet for vann- og avløpsvannapplikasjoner

VLT® AQUA Drive er designet for å gi høyeste ytelsesnivå for AC motordrevne vann- og avløpsvannapplikasjoner. Frekvensomformeren har et bredt utvalg av nyttige standardfunksjoner som kan utvides med opsjoner som forbedrer yteevnen til både nye prosjekter og rehabiliteringsprosjekter.

Den betydelige variasjon i daglig belastning ved renseanlegg gjør det økonomisk mulig å integrere motorstyring på roterende utstyr f.eks. pumper og vifter. Den nye generasjonen VLT® AQUA Drive kan realistisk tilby besparelser det første året på mellom 10 og 30% sammenlignet med tradisjonelle frekvensomformerløsninger. Den lange levetiden og lave energiforbruket og kostnader til vedlikehold gir deg lave eierkostnader.

Den enkle og brukervennlige konfigurasjonen av vann- og pumpeinnstillinger reduserer installasjonstid og sikrer maksimal energieffektivitet og motorstyring. Når de viktigste parameterne er samlet på ett sted, reduseres risikoen for feil konfigurasjon betydelig.

Godkjent av Verdensalliansen for effektive løsninger som en solimpulseffektiv løsning.

De 1000 effektive løsninger er det beste verden har å tilby i rene løsninger for å beskytte miljøet. VLT® AQUA Drive FC 202 ble vurdert utifra kriteriene for levedyktighet, implementerbarhet og bæredyktighet.

Forsyningsspenninger og effektområde

  • 1 x 200–240 V til 1,1–22 kW
  • 1 x 380–480 V til 7,5–37 kW
  • 3 x 200–240 V til 0,25–45 kW
  • 3 x 380–480 V til 0,37 kW – 1 MW
  • 3 x 525–600 V til 0,75–90 kW
  • 3 x 525–690 V til 1,1 kW – 1,4 MW

Low Harmonic Drive

  • 3 x 380-480 V til 132-450 kW

12-pulset frekvensomformer

  • 3 x 380-500 til 250-1000 kW
  • 3 x 525-690 til 250-1400 kW

Funksjoner og fordeler

Ressurser beskyttes takket være spesialutviklet programvare som forhindrer for eksempel vannslag.

Energieffektiviteten maksimeres som følge av styrealgoritmer og utførelser som fokuserer på å redusere varmetap

Høye energibesparelser ved klimaanlegg sikres takket være det unike konseptet med bakkanalkjøling som fører 90 % av varmen vekk fra rommet

Elektromagnetisk interferens og oversvingninger reduseres takket være det innebygde, skalerbare RFI-filteret og de integrerte nettdroslene

Perfekt systemintegrering og tilpasning til bruksområdet er mulig takket være fritt programmerbare advarsler og alarmer

3–8 % energibesparelser oppnås som følge av automatisk energioptimering

Se hvordan VLT® AQUA Drive leverer  optimal omkostningseffektivitet

Se hvordan VLT® AQUA Drive leverer optimal omkostningseffektivitet
