T-series, for tough applications


With pressure capability up to 350 bar [5,080 psi] and high starting torque, the T-series is the energy-efficient choice for the toughest working environments.
Leading performance with a long lifetime makes light work of the heaviest duties. Up against high pressures, thin oil or frequent reversals, our motors are guaranteed to perform smoothly and efficiently - even at low speed.

T-series characteristics

Motors with speed sensor

Ultra short motors

Motors with integrated brake

Motors with integrated flushing valve

Special dust seal ring for additional shaft seal protection

Features and benefits

High bearing capacity and robust cardan shaft design for longer life

Outstanding motor efficiency for reduced fuel consumption

Low leakage, securing energy savings

Short motors without bearings for compact integration in gear boxes and other flexible design options

Integrated flushing valve for continuous oil renewal and cooling in a closed circuit

Special mounting flange on wheel motors for optimal utilization of bearing capacity

Product range

Our large orbital motors are an excellent choice for the propel and work functions on many applications – including skid steer loaders, trench compactors, forestry harvester heads, and beet harvesters.

TMK

Type

TMK

Displacement [cm³/rev] [Min]

Displacement [cm³/rev] [Max]

Displacement [in³/rev] [Min]

Displacement [in³/rev] [Max]

Continuous oil flow [L/min] [Max]

Continuous oil flow [gal/min] [Max]

Intermediate output [hp] [Max]

Intermediate output [kW] [Max]

Intermediate pressure drop [bar] [Max]

Intermediate pressure drop [psi] [Max]



160

470

9.77

28.68

80

21.1

36

27

325

4715



TMT

Type

TMT

Displacement [cm³/rev] [Min]

Displacement [cm³/rev] [Max]

Displacement [in³/rev] [Min]

Displacement [in³/rev] [Max]

Continuous oil flow [L/min] [Max]

Continuous oil flow [gal/min] [Max]

Intermediate output [hp] [Max]

Intermediate output [kW] [Max]

Intermediate pressure drop [bar] [Max]

Intermediate pressure drop [psi] [Max]

250

630

15.37

38.39

125

33

68

51

350

5080

TMT
TMTHW

Type

TMTHW

Displacement [cm³/rev] [Min]

Displacement [cm³/rev] [Max]

Displacement [in³/rev] [Min]

Displacement [in³/rev] [Max]

Continuous oil flow [L/min] [Max]

Continuous oil flow [gal/min] [Max]

Intermediate output [hp] [Max]

Intermediate output [kW] [Max]

Intermediate pressure drop [bar] [Max]

Intermediate pressure drop [psi] [Max]



315

800

18.5

48.82

200

52.8

87

65

350

5080

TMV

Type

 TMV

Displacement [cm³/rev] [Min]

Displacement [cm³/rev] [Max]

Displacement [in³/rev] [Min]

Displacement [in³/rev] [Max]

Continuous oil flow [L/min] [Max]

Continuous oil flow [gal/min] [Max]

Intermediate output [hp] [Max]

Intermediate output [kW] [Max]

Intermediate pressure drop [bar] [Max]

Intermediate pressure drop [psi] [Max]

400

800

24.41

48.82

200

52.8

150

112

350

5080



TMV

Documents

Type Name Language Updated Download File type
User guide - BC TMK/TMKW/TMK FL Orbital Motors Technical Information Japanese 31 Aug, 2018 3.1 MB .pdf
User guide - BC TMK/TMKW/TMK FL Orbital Motors Technical Information English 30 Nov, 2018 3.9 MB .pdf
User guide - BC TMT/TMTU/TMTW/TMT FL Orbital Motors Technical Information English 21 Nov, 2018 7.7 MB .pdf
User guide - BC TMT/TMTU/TMTW/TMT FL Orbital Motors Technical Information Japanese 31 Aug, 2018 4.5 MB .pdf
Data sheet - AI TMTHW Orbital Motor Data Sheet English 21 Nov, 2018 499.6 KB .pdf
User guide - BC TMTHW Orbital Motor Technical Information Manual English 21 Nov, 2018 1.3 MB .pdf
User guide - BC TMVW Orbital motor Technical Information Manual English 23 Oct, 2018 1.6 MB .pdf
User guide - BC TMVW Orbital motor Technical Information Manual Japanese 23 Aug, 2018 1.0 MB .pdf
