StarCO₂mpressors for electric buses and trains

StarCO₂mpressors HR40 and HR60: Naturally Innovative Air Conditioning Solutions

Introducing the Danfoss BOCK® CO2 StarCO₂mpressors HR40 and HR60 - a game-changer in electric bus and train air conditioning. Our innovative "star" drive design offers space-saving roof installation with the industry's lowest overall height and weight.

Experience energy-efficient and eco-friendly heat generation through a CO₂ heat pump, even in frigid -20 °C conditions, without the need for auxiliary heaters. Embrace innovation for a greener future!

Key Benefits for Manufacturers and Transport Companies:

Economically and ecologically sustainable: Secured competitive advantages through an investment that is both economically and ecologically sustainable, recognized with the Busworld Innovation Award Label in 2019.
Innovative technology: Utilizes innovative radial piston technology specifically designed for mobile CO₂ applications, ensuring efficiency and reliability.
Robust construction: Features a welded, robust steel housing with the lowest risk of leakage, guaranteeing durability and safety.
Space-saving design: Boasts the lowest overall height (219mm) and weight (81kg) in its power class, optimizing space utilization in vehicles.
Versatile performance: Offers a wide speed range to cover diverse power requirements for vehicle air conditioning, heating, and battery conditioning, enhancing versatility.
Tailored oil management: Includes specially adapted oil management tailored for vehicle applications, ensuring smooth operation.
Proven Reliability: Demonstrates proven practicality through successful series operations, instilling confidence in performance.
Robust Valve Design: Features a robust ring valve design, enhancing overall reliability and longevity.

Features and benefits of StarCO₂mpressors for electric buses and trains:

Compact efficiency: innovative "star" drive design with radial piston cylinders arranged in a star configuration around the crankshaft, offering an extremely compact compressor perfectly suited for CO₂ refrigerant (R744) and mobile applications.
Energy efficiency: eliminates the need for energy-consuming auxiliary heaters, achieving up to 20% higher efficiency with the CO₂ heat pump.
Extended vehicle range: provides approximately 40% more vehicle range, enhancing mobility and reducing operational costs.

Product features (quick overview)

Four-cylinder radial reciprocating compressor HR40 and HR60
Max. permissible overpressure: 150 bar/100 bar (HP/LP)
Weight: 81 kg
Height: approx. 219 mm, overall length: 600 mm
Wide speed range from 750 to 4,350 rpm / 12.5-75 Hz (HR60 65 Hz) for heat pump application and thermal management
Maximum permissible inclination: 22° continuous operation, 30° short term
Pipe connection with flange connection, optional solder flange
Displacement at 50 Hz / 2,900 1/min: HR40: 7.3 m³/h / HR60: 10,9 m³/h
Cooling capacity¹⁾HR40: 7 - 35 kW/ HR60: 9 - 47 kW
Heating capacity²⁾HR40: 4 - 27 kW/ HR60: 6 - 35 kW

¹⁾ +10°C/ 40°C (100 bar) / 10 K
²⁾ -20°C / +25°C (80 bar) /10 K

Radial reciprocating piston technology

Specifically developed for mobile CO₂ applications

Efficient reciprocating piston technology, especially part-load optimised for heat pump applications
Very wide speed range
Lowest overall height, lowest weight
Welded housing with reduced interfaces for lowest risk of leakage
Space-saving roof installation in electric buses and trains
Robust and reliable, proven in practice

Environmentally friendly and future-proof

Air conditioning and heating with climate-neutral refrigerant R744

Natural, non-flammable refrigerant
Climate neutral: no ozone depletion potential (ODP = 0)
The lowest global warming potential (GWP = 1)
Efficient operation of heat pumps down to an outside temperature of -20 °C
Up to 75% energy savings compared to electric heating
Meets the criteria of the "Blue Angel" Eco-label
Meets the subsidy requirements for electric bus air conditioners in Germany

BOCK® compressors with R744/CO₂ as refrigerant

Environmentally Friendly and Cost-Effective: CO₂ is a natural, eco-friendly, and economical refrigerant compared to fluorinated alternatives. It's non-toxic, non-flammable, and colorless.
Low Environmental Impact: CO₂, with a GWP value of 1, isn't subject to the F-Gas Regulation's "Phase-Down Scenario." Leak tests are only mandatory for systems with a 5-tonne CO₂ equivalent charge, saving on testing costs.
No Costly Recovery: CO₂ release during service work doesn't necessitate expensive refrigerant recovery, reducing maintenance expenses.
Expert Support: CO₂ systems can have demanding characteristics, including high pressure and low critical points.
