Absorbs and dissipates huge thermal loads

By combining clutches and brakes into compact, all-in-one units, we can tailor packages to meet the requirements of your specific applications. Airflex combination clutch and brake packages feature a range of speeds, engagements and cycle types to provide the power you need.

  • Optimal performance - air-actuated disc clutch
  • Stopping power - spring-applied disc brake
  • Several packages - variety of applications

Three clutches/brake packages

  • CBC – Ideal for automatic punching machines, press brakes, printing machines, shears, stamping and forming presses, woodworking machines and much more
  • FSPA – Designed primarily for stamping press applications; can be easily adapted to other types of flywheel machinery requiring cyclic operation
  • DCB – Specifically designed for high-speed, continuously running can-making machinery

Air-actuated clutch and spring-applied disc brake units

All Danfoss combination packages feature an air-actuated clutch and a spring-applied disc brake for optimal performance and stopping power.

Features and benefits

CBC
  • Compact design, high thermal capacity and low air consumption is ideal for high speed, high cyclic, heavy-duty industrial applications
  • Overlapping cannot occur between the clutching and braking
  • Clutch capacities available up to 788,000 lb•in (58,073 N•m)
  • Brake capacities available up to 372,000 lb•in (42,029 N•m)
  • Available in 9 standard sizes
FSPA
  • Compact packages include a CB or VC clutch element, a CS, CSA or CTE spring-applied air-released brake, a flywheel or bullgear with anti-friction bearings, clutch and brake drums, quick-release valves, and a rotorseal
  • Clutch capacities available up to 516,000 lb•in (58,260 N•m)
  • Brake capacities available up to 336,200 lb•in (37,960 N•m)
  • Available in a wide range of standard sizes
DCB
  • Patented quick release air manifold provides fast clutch/brake response; stopping the ram to prevent die damage due to material misfeed
  • Overlapping cannot occur between clutching and braking
  • Clutch capacities available up to 75,000 lb•in (8,475 N•m)
  • Brake capacities available up to 55,000 lb•in (6,215 N•m)
  • Available in two standard sizes: 21DCB, 29DCB
Applications
  • Can making machines
  • Press brakes
  • Printing machines
  • Stamping & forming presses
  • Automatic punching machines
  • Shears
